LG 98UH5J-H Signage Display

LG 98UH5J-H. Product design: Digital signage flat panel. Display diagonal: 2.49 m (98"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black

Appropriate Display Brightness
With a recommend brightness of 500 cd/m² for indoor display, the UH5J-H series clearly delivers content and attracts public attention, making it the most suitable display for marketing in meeting rooms, airports, retail, shopping malls, etc.

High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.

Conformal Coating
In various places the UH5J-H series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting UH5J-H series from salt, dust, iron powder, humidity, etc.

Mobile Content Management
You can create a store profile and get template recommendations using the Promota* app. Users can customize templates as needed and easily create and manage content not only on PCs but also on mobile devices.

IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.

Compatible with AV Control System
The UH5J-H series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.

Display

LED backlighting type: Direct-LED
Display diagonal: 2.49 m (98")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 500 cd/m²
HD type: 4K Ultra HD
Response time: 8 ms
Contrast ratio (typical): 1200:1
Contrast ratio (dynamic): 1000000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Panel life: 50000 h
Native refresh rate: 60 Hz
Haze rate: 28%

Ports & interfaces

HDMI ports quantity: 3
HDMI version: 2.2/1.4
HDMI output ports quantity: 1
Feature: DVI port
DVI-D ports quantity: 1
DisplayPorts quantity: 1
Feature: USB port
USB ports quantity: 1
USB connector type: USB Type-A
Ethernet LAN (RJ-45) ports: 1
Audio (L/R) in: 1
Audio (L/R) out: 1
Feature: RS-232C
Remote (IR) input: 1

Audio

Feature: Built-in speaker(s)

Design

Product design: Digital signage flat panel
Placement supported: Indoor
Orientation: Horizontal
Product colour: Black
Feature: VESA mounting
Panel mounting interface: 800 x 400 mm
Bezel width (bottom): 1.49 cm
Bezel width (side): 1.49 cm
Bezel width (top): 1.49 cm

Performance

Purpose: Universal
Feature: On Screen Display (OSD)
Operating hours (hours/days): 24/7

Power

Power consumption (typical): 420 W
Power consumption (off): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Heat dissipation: 1433 BTU/h

Computer system

Internal memory: 16 GB
Operating system installed: WebOS

Weight & dimensions

Display width: 2191.8 mm
Display depth: 86.1 mm
Display height: 1246.8 mm
Display weight: 66 kg

Packaging data

Package width: 2342 mm
Package depth: 420 mm
Package height: 1386 mm
Package weight: 99 kg

Packaging content

Feature: Remote control included
Feature: Batteries included
Cables included: Power

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 80%

Certificates

Certification: CB/NRTL, NewErP, FCC Class "A"/CE/KC

Network

Feature: Ethernet LAN
Feature: Wi-Fi

Features

Heat dissipation (max): 1945 BTU/h

Other features

Feature: Quick start guide
