Elo Touch Solutions Elo 2770L computer monitor

Elo Touch Solutions Elo 2770L. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 14 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 2.0. VESA mounting. Product colour: White
The bezel just got smaller.
The 2770L 27" touchscreen offers up to a 70% reduction in the bezel compared to similar models.
Built-in speakers and integrated IO.
Place it on a desktop, mount it on a wall or configure the 2770L to fit your space with VESA-compatibility. Built-in speakers and integrated IO.
Durable, energy efficient touchscreen.
Scratch-resistant glass surface. IK07 impact resistant. ES8.0 certified for greater energy efficiency.
Navigate the OSD directly on the touchscreen.
We have made it easier to manage your On-Screen Display (OSD) controls - Now you can use the touchscreen or the controls you are used to on the rear side of the monitor.

Display

Display diagonal: 68.6 cm (27")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Native aspect ratio: 16:9
Display technology: LED
Panel type: TFT
Touchscreen: Yes
Touchscreen technology: Projected capacitive system
Touch technology: Multi-touch
Number of simultaneous touchpoints: 10
Display brightness (peak): 300 cd/m²
Display brightness (typical): 270 cd/m²
Response time: 14 ms
Anti-glare screen: Yes
Screen shape: Flat
Supported graphics resolutions: 640 x 400, 640 x 480 (VGA), 720 x 400, 800 x 500, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Contrast ratio (typical): 1000:1
Maximum refresh rate: 60 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.7 million colours
Digital horizontal frequency: 30 - 82 kHz
Digital vertical frequency: 50 - 75 Hz

Performance

NVIDIA G-SYNC: No
AMD FreeSync: No

Multimedia

Number of speakers: 2
RMS rated power: 4 W
Built-in speaker(s): Yes
Built-in camera: No

Design

Market positioning: Business
Product colour: White

Ports interfaces

Built-in USB hub: Yes
USB hub version: 2.0
USB upstream port type: USB Type-A, USB Type-B
Number of USB Type-B upstream ports quantity: 1
USB Type-A downstream ports quantity: 2
USB Touch port: Yes
USB Touch ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI: Yes
HDMI ports quantity: 1
DisplayPorts quantity: 1

Ergonomics

VESA mounting: Yes
Panel mounting interface: 100 x 100 mm
Cable lock slot: No
Height adjustment: No
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese

Power

Energy efficiency class (SDR): E
Energy consumption (SDR) per 1000 hours: 18 kWh
Power consumption (typical): 19 W
Power consumption (standby): 0.5 W
Power consumption (off): 0.16 W
Power consumption (PowerSave): 16.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power supply type: External
Energy efficiency scale: A to G

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 95%

Weight dimensions

Width (without stand): 626.2 mm
Depth (without stand): 372.8 mm
Height (without stand): 43.8 mm
Weight (without stand): 6.3 kg

Packaging data

Package width: 703 mm
Package depth: 136 mm
Package height: 489 mm
Package weight: 9.45 kg
