Elo Touch Solutions 1509L

Elo Touch Solutions 1509L. Product design: Digital signage flat panel. Display diagonal: 39.6 cm (15.6"), Display technology: LED, Display resolution: 1366 x 768 pixels, Display brightness: 200 cd/m², Touchscreen. Product colour: Black
The Elo 1509L 15.6-inch widescreen LED touchscreen monitor delivers a low-profile, retail-hardened solution with a pure glass construction to allow high light transmission without compromising durability or functionality. Available with TouchPro® PCAP offering multi touch capacity, the 1509 has been "built for touch" offering an ideal solution for general applications including hospitality and retail environments.
Integrated touch.
With no moving parts to wear out, the 1509 offers a touch response that is fast, accurate, and drift-free using a finger, gloved hand, or soft stylus.
Flexible mounting.
The touchscreen monitor can be affixed to a counter, or when the stand is removed, mounted on a wall or to a pole, and with the LED backlight power consumption is significantly reduced.
Commercial grade.
The 15.6-inch touchscreen monitor delivers the quality and reliability Elo is known for and is backed by our two-year standard warranty. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.

Display

Panel type: TFT-LCD
Display diagonal: 39.6 cm (15.6")
Display technology: LED
Display resolution: 1366 x 768 pixels
Display brightness: 200 cd/m²
Touchscreen: Yes
Touchscreen technology: Projected capacitive system
Multi-touch: Yes
Response time: 12 ms
Contrast ratio (typical): 500:1
Viewing angle, horizontal: 90°
Viewing angle, vertical: 60°
Active display area (W x H): 344.23 x 193.55 mm
Display diagonal (metric): 419.1 cm
Number of displays: 1
Horizontal scan range: 31.5 - 82 kHz
Vertical scan range: 50 - 75 Hz
Native refresh rate: 60 Hz

Ports interfaces

HDMI ports quantity: 1
USB port: Yes
USB connector type: USB Type-B
DC-in jack: Yes

Audio

Built-in speaker(s): No

Design

Product design: Digital signage flat panel
Orientation: Horizontal
Product colour: Black
Screen shape: Flat
VESA mounting: Yes
Panel mounting interface: 75 x 75,100 x 100 mm
Stand type: Center stand

Performance

On Screen Display (OSD): Yes
Number of OSD languages: 8
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese
International Protection (IP) code: IPX1
Mean time between failures (MTBF): 50000 h

Power

Power consumption (typical): 6.41 W
Power consumption (sleep): 0.84 W
Power consumption (off): 0.21 W
Energy efficiency class (SDR): C
Energy consumption (SDR) per 1000 hours: 8 kWh
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G

Weight dimensions

Width (with stand): 283.4 mm
Depth (with stand): 173.5 mm
Height (with stand): 387.1 mm
Weight (with stand): 2.64 kg

Packaging data

Package width: 450 mm
Package depth: 260 mm
Package height: 326 mm
Package weight: 4.76 kg

Packaging content

Stand included: Yes
Stand colour: Black
Cables included: USB Type-A to USB Type-B, VGA

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 95%

Logistics data

Quantity per pack: 1 pc(s)

Other features

Manual: Yes
Aspect ratio: 16:9
