22" Signage with More Utility for Commercial Space
22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.
High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.
A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.
USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.
Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.
Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client's business.
| AC įėjimo dažnis | 50 - 60 Hz |
| AC įėjimo įtampa | 100 - 240 V |
| Aukštis | 302.1 mm |
| Bruto svoris | 4.65 kg |
| Darbo santykinės drėgmės diapazonas | 10 - 80 % |
| Darbo temperatūros diapazonas (TT) | 0 - 40 °C |
| Darbo valandos (valandos / dienos) | 16/7 |
| Darniosios sistemos (DS) kodas | 85285210 |
| DVI prievadas | Ne |
| Ekrano rezoliucija | 1920 x 1080 pikseliai |
| Ekrano ryškumas | 250 cd/m² |
| Ekrano technologija | IPS |
| Ekrano įstrižainė | 21.5 " |
| Ekrano įstrižainės dydis (metrinė) | 55.88 cm |
| Energijos suvartojimas | 33 W |
| Energijos suvartojimas (laukimo režimu) | 30 W |
| Energijos suvartojimas (off) | 0.5 W |
| Energijos suvartojimas (sleep mode) | 1 W |
| Ethernet LAN (RJ-45) portų kiekis | 1 |
| Ethernet LAN jungtis | Taip |
| Gaminio konstrukcija | Skaitmeninis informacinis plokščias ekranas |
| Garso (kairė, dešinė) įvestis | 1 |
| HD tipas | "Full HD" |
| HDMI portų kiekis | 2 |
| Ilgis | 53.8 mm |
| Integruotas procesorius | Taip |
| Kompiuterio sistema | Ne |
| Kontrasto santykis (dinaminis) | 400000:1 |
| Kontrasto santykis (tipinis) | 1000:1 |
| Lietimui jautrus ekranas | Ne |
| Matymo kampas, horizontalus | 178 ° |
| Matymo kampas, vertikalus | 178 ° |
| Model | 22SM3G-B |
| Model name | 22SM3G-B Digital signage display 54.6 cm (21.5') IPS Wi-Fi 250 cd/m² Full HD Black Built-in processor 16/7 |
| Montavimo rinkinys | Taip |
| Natūralus kraštinių santykis | 16:9 |
| Neto svoris | 3.34 kg |
| Orientacija | Horizontalus |
| Paketo svoris | 3500 g |
| Pakuotės aukštis | 357 mm |
| Pakuotės gylis | 103 mm |
| Pakuotės plotis | 565 mm |
| Paskirtis | Universalus |
| Plotis | 510.3 mm |
| Pridedamas nuotolinio valdymo pultelis | Taip |
| Pridėti kabeliai | AC |
| Pridėtos baterijos | Taip |
| Procesoriaus branduoliai | 4 |
| Produkto spalva | Juoda |
| RMS galingumas | 2 W |
| RS-232 sąsaja | Taip |
| RS-232C | Taip |
| Sandėliavimo santykinis drėgmės diapazonas | 5 - 85 % |
| Sandėliavimo temperatūros norma (T-T) | -20 - 60 °C |
| Sertifikavimas | CB, NRTL, EMC, FCC Class "A", CE, ErP |
| Shipping Box Depth | 57.5 cm |
| Shipping Box Height | 37 cm |
| Shipping Box Weight | 4.65 kg |
| Shipping Box Width | 11.5 cm |
| Suderinama su VESA sienos tvirtinimo sistema | 100 x 100 mm |
| Summary | LG 22SM3G-B Digital signage display 54.6 cm (21.5') IPS Wi-Fi 250 cd/m² Full HD Black Built-in processor 16/7. Product design: Digital signage flat panel. Display diagonal: 54.6 cm (21.5"), Display technology: IPS, Display resolution: 1920 x 1080 pixels, Display brightness: 250 cd/m², HD type: Full HD. Wi-Fi. Operating hours (hours/days): 16/7. Product colour: Black |
| Svoris | 3340 g |
| Unit Box Height | 0.37 |
| Unit Box Length | 0.575 |
| Unit Box Width | 0.115 |
| Unit Brutto Volume | 0.02447 cubm |
| USB prievadas | Taip |
| USB prievadų skaičius | 1 |
| USB versija | 2.0 |
| Vendor Homepage | https://www.lg.com/ae/business/information-display/digital-signage/lg-22SM3G-B |
| VESA tvirtinimo pagrindas | Taip |
| Vidinė atmintis | 4 GB |
| Vieneto aukštis | 37 cm |
| Vieneto gylis | 57.5 cm |
| Vieneto plotis | 11.5 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 1 |
| Įmontuoti garsiakalbiai | Taip |
| Įmontuotų garsakalbių skaičius | 2 |
| Šilumos sklaida | 7.89 BTU/h |
| "Wi-Fi" | Taip |
