DISPLAY LCD 22" / 22SM3G-B LG
Product reference: 2-8806098661039

DISPLAY LCD 22" / 22SM3G-B LG

Product reference: 2-8806098661039
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
314,90 €
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

22" Signage with More Utility for Commercial Space
22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.

High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.

Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.

A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.

USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.

Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.

Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client's business.

  • Brightness(Typ.) : 250 cd/m²
  • Bezel : 16.3mm
  • Depth : 53.8mm
  • Interface : HDMI(2) / USB 2.0 / RS232C / RJ45 / IR / Audio
  • USB Plug & Play, Built-in Wi-Fi

AC įėjimo dažnis 50 - 60 Hz
AC įėjimo įtampa 100 - 240 V
Aukštis 302.1 mm
Bruto svoris 4.65 kg
Darbo santykinės drėgmės diapazonas 10 - 80 %
Darbo temperatūros diapazonas (TT) 0 - 40 °C
Darbo valandos (valandos / dienos) 16/7
Darniosios sistemos (DS) kodas 85285210
DVI prievadas Ne
Ekrano rezoliucija 1920 x 1080 pikseliai
Ekrano ryškumas 250 cd/m²
Ekrano technologija IPS
Ekrano įstrižainė 21.5 "
Ekrano įstrižainės dydis (metrinė) 55.88 cm
Energijos suvartojimas 33 W
Energijos suvartojimas (laukimo režimu) 30 W
Energijos suvartojimas (off) 0.5 W
Energijos suvartojimas (sleep mode) 1 W
Ethernet LAN (RJ-45) portų kiekis 1
Ethernet LAN jungtis Taip
Gaminio konstrukcija Skaitmeninis informacinis plokščias ekranas
Garso (kairė, dešinė) įvestis 1
HD tipas "Full HD"
HDMI portų kiekis 2
Ilgis 53.8 mm
Integruotas procesorius Taip
Kompiuterio sistema Ne
Kontrasto santykis (dinaminis) 400000:1
Kontrasto santykis (tipinis) 1000:1
Lietimui jautrus ekranas Ne
Matymo kampas, horizontalus 178 °
Matymo kampas, vertikalus 178 °
Model 22SM3G-B
Model name 22SM3G-B Digital signage display 54.6 cm (21.5') IPS Wi-Fi 250 cd/m² Full HD Black Built-in processor 16/7
Montavimo rinkinys Taip
Natūralus kraštinių santykis 16:9
Neto svoris 3.34 kg
Orientacija Horizontalus
Paketo svoris 3500 g
Pakuotės aukštis 357 mm
Pakuotės gylis 103 mm
Pakuotės plotis 565 mm
Paskirtis Universalus
Plotis 510.3 mm
Pridedamas nuotolinio valdymo pultelis Taip
Pridėti kabeliai AC
Pridėtos baterijos Taip
Procesoriaus branduoliai 4
Produkto spalva Juoda
RMS galingumas 2 W
RS-232 sąsaja Taip
RS-232C Taip
Sandėliavimo santykinis drėgmės diapazonas 5 - 85 %
Sandėliavimo temperatūros norma (T-T) -20 - 60 °C
Sertifikavimas CB, NRTL, EMC, FCC Class "A", CE, ErP
Shipping Box Depth 57.5 cm
Shipping Box Height 37 cm
Shipping Box Weight 4.65 kg
Shipping Box Width 11.5 cm
Suderinama su VESA sienos tvirtinimo sistema 100 x 100 mm
Summary LG 22SM3G-B Digital signage display 54.6 cm (21.5') IPS Wi-Fi 250 cd/m² Full HD Black Built-in processor 16/7. Product design: Digital signage flat panel. Display diagonal: 54.6 cm (21.5"), Display technology: IPS, Display resolution: 1920 x 1080 pixels, Display brightness: 250 cd/m², HD type: Full HD. Wi-Fi. Operating hours (hours/days): 16/7. Product colour: Black
Svoris 3340 g
Unit Box Height 0.37
Unit Box Length 0.575
Unit Box Width 0.115
Unit Brutto Volume 0.02447 cubm
USB prievadas Taip
USB prievadų skaičius 1
USB versija 2.0
Vendor Homepage https://www.lg.com/ae/business/information-display/digital-signage/lg-22SM3G-B
VESA tvirtinimo pagrindas Taip
Vidinė atmintis 4 GB
Vieneto aukštis 37 cm
Vieneto gylis 57.5 cm
Vieneto plotis 11.5 cm
Vienetų skaičius vienoje siuntimo dėžėje 1
Įmontuoti garsiakalbiai Taip
Įmontuotų garsakalbių skaičius 2
Šilumos sklaida 7.89 BTU/h
"Wi-Fi" Taip
