Avocor W series W5555 interactive whiteboard

Avocor W series AVW-5555, 55" InGlass™ All-in-One Interactive Display. Display diagonal: 139.7 cm (55"), Display brightness: 500 cd/m², Display resolution: 3840 x 2160 pixels. Speaker power: 40 W. USB connector type: USB Type-A, USB Type-B, USB Type-C, USB Power Delivery up to: 60 W. Product colour: Black, Panel mounting interface: 400 x 400 mm, Power cable length: 3 m. Power consumption (max): 310 W, Power consumption (standby): 0.5 W, AC input voltage: 100 - 240 V

The Avocor W series interactive displays have integrated features and performance to help keep people connected. Ideal for focus and small meeting rooms, corporate and home offices, the all-in-one AVW-5555 offers an integrated, high-quality conference camera with a microphone array and audio optimized for use with UC platforms, including Microsoft Teams, RingCentral, and Zoom, the Avocor W series is the ideal platform to create the perfect video collaboration environment.

Display

Display diagonal: 139.7 cm (55")
Display brightness: 500 cd/m²
Display resolution: 3840 x 2160 pixels
Feature: Anti-glare screen
LED backlighting type: Direct-lit LED
Native aspect ratio: 16:9
Contrast ratio (typical): 4000:1
Response time: 8 ms
Feature: Touchscreen
Touch technology: Multi-touch
Number of simultaneous touchpoints: 20
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Screen glass thickness: 3 mm
Feature: Pen & touch differentiation
Feature: Palm erase
Feature: Palm rejection

Audio

Feature: Built-in speaker(s)
Number of built-in speakers: 4
Speaker power: 40 W
Feature: Built-in microphone
Number of microphone arrays: 4

Ports & interfaces

USB connector type: USB Type-A, USB Type-B, USB Type-C
USB 2.0 Type-A hub ports quantity: 2
USB 2.0 Type-B Touch ports quantity: 2
HDMI ports quantity: 2
USB Type-C ports quantity: 1
HDMI version: 2.0
HDMI output ports quantity: 1
Feature: USB Power Delivery (USB PD)
USB Power Delivery up to: 60 W
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 2
Feature: Line-out
OPS slot: 1
Feature: S/PDIF out port
RS-232 ports: 1

Ergonomics

Product colour: Black
Feature: VESA mounting
Panel mounting interface: 400 x 400 mm
Power cable length: 3 m

Performance

Feature: Ambient light sensor
Feature: Proximity sensor
Feature: Temperature sensor

Power

Power consumption (max): 310 W
Power consumption (standby): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz

System requirements

Windows operating systems supported: Windows 10, Windows 8
Feature: Mac compatibility
Mac operating systems supported: Yes
Linux operating systems supported: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C

Weight & dimensions

Width: 1280 mm
Depth: 102 mm
Height: 863 mm
Weight: 45.3 kg

Packaging data

Package width: 1495 mm
Package depth: 260 mm
Package height: 1026 mm
Package weight: 59.2 kg

Packaging content

USB cable length: 3 m
Cables included: HDMI, Power, USB Type-A to USB Type-B, USB Type-C to USB Type-C
Feature: Remote control included
Feature: Batteries included
Feature: Quick start guide
Feature: Stylus included
Stylus pen type: Passive
Number of stylus pens: 2
Stylus tip diameter: 3 mm

Other features

Warranty period: 3 year(s)
Country of origin: Taiwan
