AG Neovo QM-6502

AG Neovo QM-6502. Product design: Digital signage flat panel. Display diagonal: 163.8 cm (64.5"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 400 cd/m², HD type: 4K Ultra HD. Product colour: Black

The new QM-Series 4K digital signage displays are designed for digital signage applications that require crisper and clearer image presentation. Featuring a premium IPS panel for 24/7 operation, 4K UHD resolution with a wide viewing angle, and easy-to-use media playback via a USB drive. The QM-Series 4K digital signage displays are ideally used for retail stores, corporate meeting areas, hotels and
other public spaces.

Display

Panel type: IPS
Feature: LED backlight
Display diagonal: 163.8 cm (64.5")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 400 cd/m²
HD type: 4K Ultra HD
Response time: 5 ms
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Pixel pitch: 0.372 x 0.372 mm
Horizontal scan range: 15 - 136 kHz
Vertical scan range: 23 - 76 Hz
Haze rate: 1%
Surface hardness: 3H

Ports & interfaces

HDMI ports quantity: 3
HDMI version: 2.0
VGA (D-Sub) input ports: 1
Feature: USB port
USB ports quantity: 1
USB version: 2.0
Ethernet LAN (RJ-45) ports: 1
Feature: Microphone in
Feature: RS-232 interface
Feature: PC Audio out

Audio

Feature: Built-in speaker(s)
Number of built-in speakers: 2
RMS rated power: 20 W

Design

Product design: Digital signage flat panel
Placement supported: Indoor
Product colour: Black
Feature: VESA mounting
Panel mounting interface: 400 x 400 mm
Feature: Anti-glare screen

Performance

Purpose: Commercial

Power

Power consumption (typical): 167 W
Power consumption (standby): 0.5 W
Input voltage: 100 - 240 V
Power consumption (off): 0.3 W
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 167 kWh
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G

Weight & dimensions

Display width: 1462.3 mm
Display depth: 81 mm
Display height: 837.3 mm
Display weight: 28.5 kg

Packaging data

Package width: 1580 mm
Package depth: 151 mm
Package height: 1050 mm
Package weight: 33.8 kg

Packaging content

Feature: Batteries included
Feature: Power adapter included
Cables included: AC, HDMI

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 90%

Network

Feature: Ethernet LAN

Technical details

Feature: Sustainability compliance
Compliance certificates: CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE

Other features

Feature: Quick start guide
Cable lock slot type: Kensington
