Yealink W70B DECT base station

Yealink W70B. Maximum range: 300 m, Management protocols: SNTP/NTP, UDP/TCP/TLS, Security algorithms: AES, HTTPS, SHA-256, SHA-384, SHA-512, TLS. Phonebook capacity (per handset): 1000 entries. Frequency range (EU): 1880 - 1900 MHz, Frequency range (US): 1920 - 1930 MHz. Ethernet LAN data rate supported (max): 100 Mbit/s. Product colour: Grey, Certification: CE, FCC, REACH

High-performance DECT IP base station for small and medium-sized businesses
The Yealink W70B is the DECT IP base station for small and medium-sized businesses. Paring with up to a total of 10 Yealink W73H/W56H/W59R/CP930W/color screen DDPhone (T54W+DD10K) DECT handsets, W70B allows you to enjoy superb mobility and efficient flexibility immediately as well as significantly eliminates additional wiring troubles and charges. A powerful chip ensuring a better and higher performance, this DECT IP base station not only supports up to 10 VoIP accounts and 20 simultaneous calls, but also speeds up its startup and signal connection, provides no perception upgrade, slashes its upgrade downtime as well.

Designed in modern and elegant style, this compact DECT IP base station possesses a wire-hidden design, presenting a concise and tidy desk to you even being mounted to the wall. By supporting Opus codec, Yealink W70B consistently delivers excellent and professional audio quality in both high-bandwidth and poor network conditions, comparing with other wideband or narrowband audio

The Yealink W70B DECT IP base station supports efficient provisioning and effortless mass deployment with Yealink's Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings, which makes it simple to deploy, easy to maintain and upgrade, saving even more time and IT costs for businesses

Performance

Number of handsets supported (max): 10
Maximum range: 300 m
CAT-iq: 2.0
Number of VoIP accounts: 10
Management protocols: SNTP/NTP, UDP/TCP/TLS
Security algorithms: AES, HTTPS, SHA-256, SHA-384, SHA-512, TLS
DECT standards: CAT-iq2.0
Voice codecs: AGC, AJB, AMR-WB, CNG, G.722, G.726, G.729, G.729A, PLC, VAD, iLBC
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Hearing aid compatibility: Yes
Feature: Music on hold function
Feature: XML browser
Feature: Auto-provision

Call management

Feature: Conference call
Number of parallel conferences: 3
Phonebook capacity (per handset): 1000 entries
Number of simultaneous calls (max): 20
Feature: Anonymous call
Feature: Anonymous call rejection
Feature: Call waiting
Feature: Call forwarding
Feature: Caller ID
Feature: Remote phonebook
Feature: Call transfer
Feature: Call hold
Feature: Switching between calls
Feature: Mute function
Feature: Speed dialling
Feature: Integrated voicemail
Feature: Redialing
Feature: Message Waiting Indication (MWI) function
Feature: Phonebook search/import/export function
Feature: Call history
Feature: Reset function
Feature: Emergency call
Feature: Shared Call Appearance (SCA)
Feature: System log export

Antenna

Frequency range (EU): 1880 - 1900 MHz
Frequency range (US): 1920 - 1930 MHz

Ports & interfaces

Feature: Ethernet LAN
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rate supported (max): 100 Mbit/s

Design

Product colour: Grey
Feature: Full duplex
Feature: Wall mountable
LED indicators: Yes
Certification: CE, FCC, REACH

Power

Input voltage: 100 - 240 V
Output voltage: 5 V
Output current: 0.6 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 95%

Weight & dimensions

Dimensions (WxDxH): 130 x 100 x 25.1 mm
Weight: 3.61 kg
Package width: 174 mm
Package depth: 180 mm
Package height: 63 mm
Package weight: 4.15 kg

Packaging content

Feature: Quick start guide
Feature: Power adapter included
