Meter - Uni-T UT17B MAX True RMS Digital Multimeter 6000 Counts Display, Black
Product reference: 14-6935750517192

The Uni-T UT17B MAX is a true RMS digital multimeter that measures AC and DC voltage, current, resistance, capacitance, frequency and temperature. It features a 6000-count display, adjustable backlight and a Type K thermocouple for quick temperature measurements.

Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas
Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas
Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas
Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas
Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas
Matuoklis - Uni-T UT17B MAX True RMS Skaitmeninis Multimetras 6000 Skaičių Ekranas Juodas

Meter - Uni-T UT17B MAX True RMS Digital Multimeter 6000 Counts Display, Black

Product reference: 14-6935750517192

The Uni-T UT17B MAX is a true RMS digital multimeter that measures AC and DC voltage, current, resistance, capacitance, frequency and temperature. It features a 6000-count display, adjustable backlight and a Type K thermocouple for quick temperature measurements.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
125,24 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
15 - 16
business days

Your message has been successfully sent!
Fill in the required fields*

Uni-T True RMS UT17B MAX Digital Multimeter


Uni-T UT17B MAX is a True RMS digital multimeter that measures AC and DC voltage, current, resistance, capacitance, frequency and temperature. It has a 6000-digit display, adjustable backlight and is equipped with a Type K thermocouple for instantaneous temperature measurements.


  • Measures voltage from AC/DC to 1000V, current from 10A and resistance from 60MΩ, making it versatile for various electrical diagnostic tasks.
  • Added temperature measurement function from -55°C to 500°C with Type K thermocouple, ready for instant use.
  • There is adjustable lighting, Data Hold, MAX/MIN and relative mode for easier use during diagnostics.
  • Equipped with safety features such as incorrect wire connection alarm and CAT III 600V voltage category, ensuring safe operation.

Features

Product Type Digital Multimeter
Product Brand Uni-T
Model UT17B MAX

Specifications

DC Voltage Measurement 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V ±(0.4%+3)
AC Voltage Measurement 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V ±(0.5%+5)
DC Current Measurement 600.0 µA / 6000 µA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A ±(1.2%+3)
AC Current Measurement 600.0 µA / 6000 µA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A ±(1.2%+3)
Resistance Measurement 600.0Ω to 60.00MΩ ±(0.5%+2)
Capacity Measurement 6.000nF to 6000µF ±(2.0%+5)
Frequency Measurement 10Hz ~ 10MHz ±(0.1%+3)
Temperature Measurement -55°C to 500°C ±2°C / ±4°F
Screen Number 6000
Power supply 2x 1.5V AA batteries
Weight 455 g
Dimensions 182mm × 91mm × 45mm
Voltage Category CAT III 600V

Security Warning

Use the product only for its intended purpose to avoid hazards.

Height100mm
Length300mm
Weight600g
Width200mm
