Meter - Uni-T UT161D True RMS Digital Multimeter 1000V 10A Black
Product reference:
14-6935750516164
The Uni-T UT161D is a true RMS digital multimeter capable of measuring AC/DC voltage up to 1000V and current up to 10A. It features a backlit display, wireless voltage detection, and USB connectivity for data transfer.
Meter - Uni-T UT161D True RMS Digital Multimeter 1000V 10A Black
Product reference:
14-6935750516164
The Uni-T UT161D is a true RMS digital multimeter capable of measuring AC/DC voltage up to 1000V and current up to 10A. It features a backlit display, wireless voltage detection, and USB connectivity for data transfer.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Uni-T UT161D Digital Multimeter Black
Uni-T UT161D is a True RMS digital multimeter that can measure AC/DC voltage up to 1000V and current up to 10A. It features a backlit display, non-contact voltage detection, and USB connectivity for data transfer.
- Advanced True RMS function for accurate measurement of AC and DC signals.
- Wide measurement range: up to 1000V for voltage and 10A for current, as well as temperature measurement capabilities.
- Safety features including non-contact voltage detection (NCV) and LoZ function for greater accuracy.
- Easy-to-read illuminated display with USB connection for data transfer and documentation.
Features | |
|---|---|
| Product Type | Digital Multimeter |
| Product Brand | Uni-T |
| Model | UT161D |
Specifications | |
| DC Voltage Measurement | Up to 1000V ±(0.5%+3) |
| AC Voltage Measurement | Up to 1000V ±(1.0%+3) |
| DC Current Measurement | Up to 10A ±(1.0%+2) |
| AC Current Measurement | Up to 10A ±(1.2%+5) |
| Resistance Measurement | Up to 60MΩ ±(1.0%+2) |
| Capacitor Measurement | Up to 60mF ±(3.0%+5) |
| Frequency Measurement | Up to 10MHz ±(0.1%+4) |
| Temperature Measurement | -40°C to 1000°C ±(1.0%+3) |
| Maximum Reading | 6000 |
| Dimensions | 190 × 90 × 50mm |
| Weight | 350 g |
| Power supply | 4x 1.5V AAA batteries |
| Security Class | CAT III 1000V / CAT IV 600V |
| Certificates | CE, UKCA, cETLus |
Additional Information | |
| Features | True RMS, NCV, LoZ, diode test, continuity test, Data Hold, Relative mode, Max./Min., Peak Hold, backlight, bar graph, USB connection |
| Height | 100mm |
| Length | 300mm |
| Weight | 500g |
| Width | 200mm |
