Meter - Uni-T UT15B MAX True RMS Digital Multimeter 1000V 10A 60MΩ, Black / Red
Product reference: 14-6935750515259

The Uni-T UT15B MAX is a true RMS digital multimeter that measures AC and DC voltage up to 1000 V, current up to 10 A, resistance up to 60.00 MΩ and capacitance up to 6000 µF. It features a 6000-digit display, adjustable backlight and safety features including CAT III 600V surge protection.

  • −10%
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona
Matuoklis - Uni-T UT15B MAX True RMS Skaitmeninis Multimetras 1000V 10A 60MΩ, Juoda / Raudona

Meter - Uni-T UT15B MAX True RMS Digital Multimeter 1000V 10A 60MΩ, Black / Red

Product reference: 14-6935750515259

The Uni-T UT15B MAX is a true RMS digital multimeter that measures AC and DC voltage up to 1000 V, current up to 10 A, resistance up to 60.00 MΩ and capacitance up to 6000 µF. It features a 6000-digit display, adjustable backlight and safety features including CAT III 600V surge protection.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
105,84 €
117,60 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
15 - 16
business days

Your message has been successfully sent!
Fill in the required fields*

Uni-T True RMS UT15B MAX Digital Multimeter, Black/Red


Uni-T UT15B MAX is a True RMS digital multimeter that measures AC and DC voltages up to 1000 V, currents up to 10 A, resistances from 600.0 Ω to 60.00 MΩ, and capacitances up to 6000 µF. It has a 6000-digit display, adjustable backlight, and safety features including CAT III 600V overvoltage protection.


  • AC/DC measures voltage up to 1000 V, current up to 10 A, resistance up to 60 MΩ and capacitance up to 6000 µF.
  • There is adjustable lighting, data hold, MAX/MIN and relative mode to improve usability.
  • Equipped with visual and audible alarms, including an incorrect cable connection alarm, ensuring safe use.
  • CAT III 600V overvoltage protection ensures reliability for professional use in various electrical tasks.

Features

Product Type Digital Multimeter
Product Brand Uni-T
Model UT15B MAX

Specifications

DC Voltage Meter 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V ±(0.4%+3)
AC Voltage Meter 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V ±(0.5%+5)
AC Current Meter 600.0 µA / 6000 µA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A ±(1.2%+3)
DC Current Meter 600.0 µA / 6000 µA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A ±(1.2%+3)
Resistance Meter 600.0 Ω to 60.00 MΩ ±(0.5%+2)
Capacity Meter 6,000 nF to 6,000 µF ±(2.0%+5)
Frequency Meter 10Hz ~ 10MHz ±(0.1%+3)
Screen Number 6000
Dimensions 182mm × 91mm × 45mm
Weight 455 g
Power supply 2x 1.5V AA batteries

Safety Warning

Use the product only for its intended purpose to ensure safety and accuracy.

Height100mm
Length300mm
Weight600g
Width200mm
