Clamp Meter - UNI-T UT201R 400 A True RMS AC, 600 V AC/DC, 28 mm Clamp Hole, NCV
Product reference: 14-6935750520185

UNI-T UT201R - digital current clamp meter for measuring up to 400 A AC current, up to 600 V AC and DC voltage, resistance and frequency. It features True RMS, non-contact voltage detection (NCV), circuit continuity and diode test functions, data hold, maximum and minimum readings and a backlit LCD display; the clamp mouth opens up to 28 mm.

Gnybtinis Matuoklis - UNI-T UT201R 400 A True RMS Kintamosios Srovės, 600 V Kintamosios / Nuolatinės Srovės, 28 mm Žnypl
Gnybtinis Matuoklis - UNI-T UT201R 400 A True RMS Kintamosios Srovės, 600 V Kintamosios / Nuolatinės Srovės, 28 mm Žnypl
Gnybtinis Matuoklis - UNI-T UT201R 400 A True RMS Kintamosios Srovės, 600 V Kintamosios / Nuolatinės Srovės, 28 mm Žnypl
Gnybtinis Matuoklis - UNI-T UT201R 400 A True RMS Kintamosios Srovės, 600 V Kintamosios / Nuolatinės Srovės, 28 mm Žnypl
Gnybtinis Matuoklis - UNI-T UT201R 400 A True RMS Kintamosios Srovės, 600 V Kintamosios / Nuolatinės Srovės, 28 mm Žnypl

Clamp Meter - UNI-T UT201R 400 A True RMS AC, 600 V AC/DC, 28 mm Clamp Hole, NCV

Product reference: 14-6935750520185

UNI-T UT201R - digital current clamp meter for measuring up to 400 A AC current, up to 600 V AC and DC voltage, resistance and frequency. It features True RMS, non-contact voltage detection (NCV), circuit continuity and diode test functions, data hold, maximum and minimum readings and a backlit LCD display; the clamp mouth opens up to 28 mm.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
37,61 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
15 - 16
business days

Your message has been successfully sent!
Fill in the required fields*
Not available

UNI-T UT201R


UNI-T UT201R - digital current clamp meter for measuring up to 400 A AC current, up to 600 V AC and DC voltage, resistance and frequency. It features True RMS technology, 28 mm clamp opening, non-contact voltage detection, continuity and diode testing, data hold function, maximum and minimum readings and a backlit LCD display.


  • Measure up to 400 A AC current without breaking the circuit and up to 600 V AC and DC voltage.
  • True RMS technology ensures reliable readings of alternating electrical signals.
  • The device features non-contact voltage detection, resistance, frequency, diode and continuity testing, data hold, maximum and minimum readings, and automatic shut-off.
  • Equipped with a backlit LCD display, 28 mm pliers opening; safety categories - CAT II 600 V / CAT III 300 V.

Product information

Product type Digital current clamp meter
Brand UNI-T
Model UT201R
Screen 4,000-dot LCD display with backlight

Measurement specifications

AC range 0.04-400A, ±(2% + 10)
AC voltage accuracy ±(0.8% + 5)
DC voltage accuracy ±(0.5% + 2)
AC frequency range 50-100Hz, ±(1% + 5)
Voltage frequency range 10Hz-10kHz, ±(1% + 5)
Resistance Up to 40 MΩ

Construction and power supply

Pliers hole 28 mm
Power source 2 × 1.5V R03 batteries
Dimensions 215 × 63 × 36mm

Features and safety

Measurement functions True RMS, non-contact voltage detection, diode test, continuity test, data hold, peak and minimum readings, and auto power off
Safety category CAT II 600V / CAT III 300V
Certificates CE, UKCA, cETLus
Included accessories Test leads, 2 batteries and user manual
Safety warning Use only for electrical measurements within the specified ranges and safety categories. Follow the operating instructions, select the correct measurement function and terminals, and do not clamp more than one conductor at a time. Inspect the meter and test leads before use; do not use damaged equipment or work on live circuits without proper training and protection. Keep out of reach of children.

Height100mm
Length300mm
Weight450 g
Width150mm
