Server NAS DS1823xs+ 8x0HDD 4Core V1780B 3,35Ghz 8GB DDR4 ECC 250W 5Y
Product reference:
3-4711174724956
Server NAS DS1823xs+ 8x0HDD 4Core V1780B 3,35Ghz 8GB DDR4 ECC 250W 5Y
Server NAS DS1823xs+ 8x0HDD 4Core V1780B 3,35Ghz 8GB DDR4 ECC 250W 5Y
Product reference:
3-4711174724956
Server NAS DS1823xs+ 8x0HDD 4Core V1780B 3,35Ghz 8GB DDR4 ECC 250W 5Y
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
10 - 15
business days
| Processor | |
|---|---|
| Processor frequency | 3.35 GHz |
| Processor family | Ryzen Embedded |
| Processor cores | 4 |
| Processor manufacturer | AMD |
| Number of processors supported | 1 |
| Processor model | V1780B |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor boost frequency | 3.6 GHz |
| Memory | |
| ECC | Yes |
| Internal memory | 8 GB |
| Memory form factor | SO-DIMM |
| Maximum RAM supported | 32 GB |
| Internal memory type | DDR4 |
| Memory slots | 2 |
| Design | |
| Cable lock slot | Yes |
| Built-in display | No |
| Product colour | Black |
| Cooling type | Active |
| LED indicators | Yes |
| Built-in speaker(s) | No |
| Cable lock slot type | Kensington |
| Number of fans | 2 fan(s) |
| Fan diameter | 12 cm |
| Chassis type | Tower |
| Power | |
| Number of power supply units | 1 |
| Power supply unit (PSU) capacity | 250 W |
| Power consumption (typical) | 87.93 W |
| AC input voltage | 100 - 240 V |
| Power supply location | Built-in |
| Redundant power supply (RPS) support | No |
| AC input frequency | 50 / 60 Hz |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Depth | 243 mm |
| Height | 166 mm |
| Width | 343 mm |
| Weight | 6.2 kg |
| Network | |
| Copper ethernet cabling technology | 10GBASE-T, 100BASE-TX, 1000BASE-T, 10BASE-T |
| Ethernet LAN | Yes |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| iSCSI support | Yes |
| Link aggregation | Yes |
| Ethernet LAN data rates | 10, 10000 Mbit/s, 100, 1000 Mbit/s |
| Performance | |
| Type | NAS |
| System log | Yes |
| Card reader integrated | No |
| Management protocols | SNMP |
| On/off switch | Yes |
| Backup function | Yes |
| Reset button | Yes |
| Security algorithms | AES |
| Backup features | Cloud, iSCSI LUN |
| Snapshot | Yes |
| Browser supported | Google Chrome Firefox Microsoft Edge Safari |
| Access Control List (ACL) | Yes |
| Device class | Small & Medium Business |
| Noise level | 23.6 dB |
| Multilingual support | Yes |
| Built-in FTP server | Yes |
| Packaging content | |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
| Software | |
| Server operating systems supported | Windows Server 2019 |
| Operating system installed | DiskStation Manager |
| Operating system version | 7.1.1 |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA |
| Number of M.2 (M & B) slots | 2 |
| RAID levels | 1, 5, 6, 10, 0, JBOD |
| RAID support | Yes |
| Storage drive sizes supported | 3.5", M.2, 2.5" |
| Supported file systems | ext3, NTFS, exFAT, Fat, ext4, HFS+, BTRFS |
| Number of storage drives supported | 8 |
| Storage drives installed | No |
| Online RAID migration | Yes |
| Hot-swap drive bays | Yes |
| Installed storage drive type | No |
| Total installed storage capacity | 0 TB |
| Online RAID expansion | Yes |
| Ports & interfaces | |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| eSATA ports quantity | 2 |
| USB port | Yes |
| Other features | |
| Certification | FCC BSMI VCCI RCM EAC CCC KC |
| Compliance certificates | RoHS, CE |
| Sustainability | |
| Sustainability compliance | Yes |
