Motherboard - MSI PRO B550M-P Micro ATX AM4 AMD B550 128 GB DDR4 2 M.2 4 SATA III HDMI DisplayPort VGA
Product reference:
14-4711377453547
"Micro ATX" motherboard with AMD B550 chipset and AM4 socket, supporting AMD Ryzen 3000, 4000 G-Series and 5000 G-Series processors. It can install up to 128 GB DDR4 memory, has two M.2 sockets, four SATA III connectors, Gigabit Ethernet and HDMI, DisplayPort and VGA outputs.
Motherboard - MSI PRO B550M-P Micro ATX AM4 AMD B550 128 GB DDR4 2 M.2 4 SATA III HDMI DisplayPort VGA
Product reference:
14-4711377453547
"Micro ATX" motherboard with AMD B550 chipset and AM4 socket, supporting AMD Ryzen 3000, 4000 G-Series and 5000 G-Series processors. It can install up to 128 GB DDR4 memory, has two M.2 sockets, four SATA III connectors, Gigabit Ethernet and HDMI, DisplayPort and VGA outputs.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
MSI PRO B550M-P motherboard
Micro ATX motherboard with AMD B550 chipset and AM4 socket, supporting AMD Ryzen 3000, 4000 G-Series and 5000 G-Series processors. Supports up to 128 GB DDR4 memory, has two M.2 slots, four SATA III connectors, Gigabit Ethernet and HDMI, DisplayPort and VGA outputs.
- Micro ATX motherboard with AMD B550 chipset and Socket AM4 support
- Compatible with AMD Ryzen 3000, Ryzen 4000 G-Series and Ryzen 5000 G-Series processors
- Supports up to 128 GB of DDR4 memory via four dual-channel DIMM slots
- Two M.2 slots, four SATA III connectors, Gigabit Ethernet, and HDMI, DisplayPort, and VGA outputs
Product information | |
|---|---|
| Product type | Micro ATX motherboard |
| Brand | MSI |
| Model | ABOUT B550M-P |
| Motherboard dimensions | 244 × 244 mm |
Processor and chipset | |
| Processor socket | Socket AM4 |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 3000 Series, Ryzen 4000 G-Series and Ryzen 5000 G-Series |
| Chipset | AMD B550 |
Memory | |
| Memory type | DDR4-SDRAM |
| Memory slots | 4 DIMM slots |
| Memory architecture | Two-channel |
| Maximum memory | 128GB |
| ECC support | Not ECC |
| Supported memory frequencies | 2667-4400 MHz, including 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133 and 4266 MHz |
Data warehouse | |
| Supported disc types | HDD and SSD |
| Data warehouse interfaces | M.2 and SATA III |
| SATA III connectors | 4 |
| RAID support | RAID 0, 1, and 10 |
Development and connections | |
| PCI Express x16 slot | 1 × PCI Express 4.0 |
| PCI Express x1 slots | 2 × PCI Express 3.0 |
| Internal USB ports | 4 × USB 2.0 and 3 × USB 3.2 Gen 1 |
| Internal connections | Front panel audio, front panel, TPM, and 24-pin ATX power connectors |
Audio and network features | |
| Audio codec | Realtek ALC897 |
| Audio output | 7.1 channel sound |
| LAN controller | Realtek RTL8111H |
| Network interface | Gigabit Ethernet |
| Wi-Fi | No |
Rear connections | |
| USB ports | 4 × USB 3.2 Gen 1 Type-A and 2 × USB 2.0 |
| Video outputs | 1 × HDMI, 1 × DisplayPort and 1 × VGA |
| Ethernet port | 1 × RJ-45 |
Safety information | |
| Safety warning | Install and use the motherboard only according to the manufacturer's instructions. Before installing or performing maintenance, disconnect the power supply and ensure that the board is compatible with the processor, memory, case, and power supply. Handle electronic components by their edges and protect them from static electricity, moisture, and physical damage. |
| Height | 100mm |
| Length | 350mm |
| Weight | 1300g |
| Width | 350mm |
