MSI MAG X870E TOMAHAWK MAX WIFI PZ motherboard AMD X870E Socket AM5 ATX
Product reference:
6-MAG X870E TOMAHAWK MAX WIFI PZ
MSI MAG X870E TOMAHAWK MAX WIFI PZ motherboard AMD X870E Socket AM5 ATX
MSI MAG X870E TOMAHAWK MAX WIFI PZ motherboard AMD X870E Socket AM5 ATX
Product reference:
6-MAG X870E TOMAHAWK MAX WIFI PZ
MSI MAG X870E TOMAHAWK MAX WIFI PZ motherboard AMD X870E Socket AM5 ATX
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Europe in
6 - 11
business days
| Processor manufacturer | AMD |
| Supported processor sockets | Socket AM5 |
| Compatible processor series | AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series |
| Processor socket | Socket AM5 |
| On-board graphics card | No |
| PC health monitoring | Voltage, CPU, Fan, Temperature |
| Motherboard form factor | ATX |
| Audio output channels | 7.1 channels |
| Motherboard chipset | AMD X870E |
| Motherboard chipset family | AMD |
| Product colour | White |
| Memory channels | Dual-channel |
| Supported memory types | DDR5-SDRAM |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Supported memory clock speeds | 5600, 6400, 4800 MHz, 8400 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| ECC сompatibility | Non-ECC |
| Supported memory clock speed (max) | 8400 MHz |
| Depth | 304.8 mm |
| Width | 243.8 mm |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Bluetooth version | 5.4 |
| Wi-Fi standards | 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g |
| Ethernet LAN | Yes |
| Ethernet interface type | 5 Gigabit Ethernet |
| Wi-Fi | Yes |
| LAN controller | Realtek RTL8126 |
| Bluetooth | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Total number of SATA connectors | 4 |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| Front panel connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 4 |
| Front panel audio connector | Yes |
| Number of SATA III connectors | 4 |
| USB 2.0 connectors | 4 |
| ATX Power connector (24-pin) | Yes |
| BIOS type | UEFI AMI |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 8 |
| Supported storage drive types | HDD & SSD |
| RAID levels | 1, 10 |
| RAID support | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Microphone in | Yes |
| HDMI ports quantity | 1 |
| S/PDIF out port | Yes |
| DisplayPorts quantity | 2 |
| USB 2.0 ports quantity | 4 |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB4 Gen 2x2 ports quantity | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Number of M.2 (M) slots | 4 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 1st M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| 4th M.2 largest key size | 2280 |
| 2nd M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 2280 |
| 3rd M.2 largest key size | 2280 |
| 4th M.2 highest PCI Express generation | 4.0 |
| PCI Express x16 (Gen 5.x) slots | 1 |
