Motherboard - ASRock Z890 LiveMixer WiFi ATX Intel LGA 1851
Product reference:
14-4710483949715
The ASRock Z890 LiveMixer WiFi motherboard with LGA 1851 socket supports Intel 12th and 13th generation processors, and WiFi 6E ensures fast wireless connectivity.
Motherboard - ASRock Z890 LiveMixer WiFi ATX Intel LGA 1851
Product reference:
14-4710483949715
The ASRock Z890 LiveMixer WiFi motherboard with LGA 1851 socket supports Intel 12th and 13th generation processors, and WiFi 6E ensures fast wireless connectivity.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
ASRock Z890 LiveMixer WiFi
The LGA 1851 socket supports Intel 13-osios and 12-osios generation processors. Equipped with WiFi 6E and Wi-Fi 7, ensuring fast wireless connectivity.
- Supports up to 256 GB of DDR5 non-ECC memory with a maximum frequency of 9066 MHz.
- Offers 7.1 channel audio output with Realtek ALC1220 audio chip.
- Includes two 2.5 Gigabit Ethernet and Wi-Fi 7 (802.11be) for advanced network connectivity.
- Equipped with multiple USB ports, including 2 Thunderbolt 4 and 1 USB 3.2 Gen 2x2 Type-C port.
- BIOS type: UEFI AMI with 256 Mbit memory.
Processor | |
|---|---|
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Processor socket | LGA 1851 (Socket V1) |
Features | |
| Supported Windows operating systems | Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chip | Intel Z890 |
| Motherboard format type | ATX |
| Audio chip | Realtek ALC1220 |
| Audio output channels | 7.1 channels |
Memory | |
| Memory channels | Dual channel |
| Number of memory slots | 4 |
| Supported memory types | DDR5 non-ECC |
| Maximum internal memory | 256GB |
| Supported memory frequency (max) | 9066 MHz |
Network | |
| Bluetooth version | 5.4 |
| MU-MIMO | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Wi-Fi standards | 802.11b, 802.11axe, 802.11a, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be), 802.11g |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Internal I/O | |
| Number of SATA III connectors | 4 |
| Number of USB 2.0 ports | 2 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) ports | 2 |
| Number of USB 3.2 Gen 2x2 Type-C ports | 1 |
| Number of Thunderbolt 4 ports | 2 |
| CPU cooler connector | 2 |
| ATX power connector (24-pin) | Yes |
| RGB LED pin connector | Yes |
| Front panel audio connector | Yes |
| 8-pin power connector 12 V | 2 |
| AIO pump cooler connector | 1 |
| LED and speaker power socket | 1 |
| SPI TPM socket | 1 |
BIOS | |
| BIOS type | UEFI AMI |
Memory controllers | |
| Supported memory device interfaces | Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4) |
| Height | 281 mm |
| Length | 346 mm |
| Weight | 1800g |
| Width | 75 mm |
