X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks.
The ASRock X-Series motherboard provides a high-value solution, balancing performance and versatility within a compact form factor. It's highly capable in handling a wide range of tasks, from professional productivity to everyday usage, striking an excellent balance between affordability, reliability, and efficiency.
Power Phase Design
Featuring sturdy components and completely smooth power delivery to the CPU, offering enhanced performance for gamers.
Hyper M.2 Gen4 x4
Supports PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.
Aluminum Heatsink
The first thing that catches the eye is the optimized Aluminum Heatsink Design. Heatsinks are crucial for efficient heat dissipation, especially during heavy workloads like gaming or productivity tasks. Motherboard that built with heatsinks can effectively manage thermal performance, hence ensure system stability and durability effortlessly.
Wi-Fi 6 802.11ax
Wi-Fi 6 (802.11ax) supports speeds of up to 2.4 Gbps and operates natively across both the 2.4 GHz and 5 GHz bands. It also delivers significantly improved bi-directional MU-MIMO support for more efficient multi-device connectivity.
M.2 (KEY E) For WiFi
Besides the onboard LAN port, users may also choose wireless connections by M.2 (Key E) slot.
Dragon 2.5 Gb/s LAN
The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you'll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.
Front USB 3.2 Gen1 Type-C
Front USB 3.2 Gen1 Type-C header delivers up to 5 Gbps data transfer rate and next generation reversible USB design to the front panel of computer case.
POLYCHROME RGB
This motherboard features onboard RGB headers and addressable RGB headers that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.
SignalRGB
SignalRGB unifies your RGB devices, offering seamless customization, game-reactive effects, macro automation, and system monitoring. The official partnership empowers ASRock motherboards with advanced lighting control, enhances compatibility with a diverse range of RGB devices, and provides greater customization flexibility.
| Atminties angų skaičius | 2 |
| Atminties angų tipas | DIMM |
| Atminties kanalai | Dviejų kanalų |
| ATX maitinimo jungtis | Taip |
| BIOS atminties dydis | 256 Mbit |
| BIOS tipas | UEFI AMI |
| Bluetooth | Taip |
| Bluetooth versija | 5.3 |
| Bruto svoris | 1.01 kg |
| Centrinio procesoriaus ventiliatoriaus jungčių skaičius | 1 |
| CPU fan jungtis | Taip |
| ECC suderinamumas | Ne-ECC |
| EPS maitinimo jungtis (8-kaisčiai) | Taip |
| Eterneto sąsajos tipas | 2.5 Gigabit Ethernet |
| Ethernet LAN (RJ-45) portų kiekis | 1 |
| Ethernet LAN jungtis | Taip |
| Garso išvesties kanalai | 7.1 kanalai |
| Garso lustas | Realtek ALC897 |
| HDCP | Taip |
| HDCP versija | 2.3 |
| HDMI portų kiekis | 1 |
| Ilgis | 193 mm |
| LAN kontroleris | Dragon RTL8125BG |
| M.2 (M) angų skaičius | 1 |
| Maksimali vidinė atmintis | 128 GB |
| Mikrofonas, line-in jack | Taip |
| Motininės plokštės formos faktorius | "micro ATX" |
| Motininės plokštės sisteminio valdiklio šeima | Intel |
| Nebuferizuota atmintis | Taip |
| Neto svoris | 1 kg |
| Pagrindinės plokštės lustas | Intel H810 |
| Palaikomi atminties tipai | DDR5-SDRAM |
| Palaikomi saugojimo kaupiklių sąsajos | SATA III,M.2 |
| Palaikomos "Windows" operacinės sistemos | Windows 11 x64 |
| Plotis | 244 mm |
| Pridedama antena | Taip |
| Pridėti kabeliai | SATA |
| Priekinio skydelio audio jungtis | Taip |
| Procesoriaus gamintojas | Intel |
| Procesoriaus lizdas | LGA 1851 (Socket V1) |
| Procesorių suderinamumas | Intel Core Ultra (Series 2) |
| RGB LED kontaktų pagrindas | Taip |
| SATA III jungčių skaičius | 4 |
| Shipping Box Depth | 54 cm |
| Shipping Box Height | 28 cm |
| Shipping Box Weight | 10.14 kg |
| Shipping Box Width | 31 cm |
| Summary | Asrock H810M-X Gen5 WiFi. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: SATA III, M.2. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Dragon RTL8125BG, Top Wi-Fi standard: Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel |
| Taikoma | PC |
| TPM jungtis | Taip |
| Unit Box Height | 0.265 |
| Unit Box Length | 0.26 |
| Unit Box Width | 0.06 |
| Unit Brutto Volume | 0.004687 cubm |
| USB 2.0 jungtys | 1 |
| USB 2.0 portų kiekis | 4 |
| USB 3.2 (3.1 1 kart.) A tipo prievadų skaičius | 2 |
| USB 3.2 (3.1 1 kart.) jungtys | 2 |
| Vendor Homepage | https://www.asrock.com/MB/Intel/H810M-X%20Gen5%20WiFi/index.asp#Specification |
| Vieneto aukštis | 26.5 cm |
| Vieneto gylis | 26 cm |
| Vieneto plotis | 6 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 10 |
| Wi-Fi standartai | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax) |
| Įvedimas | Taip |
| Šasi fenų jungčių skaičius | 1 |
| "DisplayPort" kiekis | 1 |
| "DisplayPort" versija | 1.4 |
| "PCI Express x1 (Gen 4.x)" lizdai | 1 |
| "PCI Express x16" ("Gen 5.x") lizdai | 1 |
| "Wi-Fi" | Taip |
| "Wi-Fi" standartas | Wi-Fi 6 (802.11ax) |
