GIGABYTE B850M D3HP Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe
Product reference:
6-B850M D3HP
GIGABYTE B850M D3HP Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 2
GIGABYTE B850M D3HP Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe
Product reference:
6-B850M D3HP
GIGABYTE B850M D3HP Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 2
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Europe in
6 - 11
business days
| Warranty period | 3 year(s) |
| Supported processor sockets | Socket AM5 |
| Processor socket | Socket AM5 |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| HDCP | Yes |
| Maximum resolution | 4096 x 2160 pixels |
| Parallel processing technology support | Not supported |
| DirectX version | 12.0 |
| Motherboard chipset | AMD B850 |
| Windows operating systems supported | Windows 11 x64, Windows 10 x64 |
| PC health monitoring | Water cooling, Temperature, Voltage, Fan |
| Audio chip | Realtek ALC897 |
| Product colour | Bronze |
| Motherboard chipset family | AMD |
| Audio output channels | 7.1 channels |
| Motherboard form factor | micro ATX |
| Power source type | ATX |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Supported memory clock speed (max) | 8200 MHz |
| Supported memory types | DDR5-SDRAM |
| Supported memory clock speeds | 8000, 6000, 5200, 6600, 6800, 6400, 6200, 6666, 7000, 8200, 4400, 5600, 7200, 7600, 7800, 4800 MHz |
| Unbuffered memory | Yes |
| Number of memory slots | 4 |
| Maximum internal memory | 256 GB |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Height | 35 mm |
| Width | 244 mm |
| Depth | 244 mm |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Wi-Fi | No |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| RGB LED pin header | Yes |
| Front panel connector | Yes |
| TPM connector | Yes |
| Serial port headers | 1 |
| Number of SATA III connectors | 4 |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| USB 2.0 connectors | 2 |
| Number of chassis fan connectors | 3 |
| 12V power connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of CPU fan connectors | 2 |
| Number of RGB LED pin headers | 4 |
| Number of EPS power connectors (8-pin) | 1 |
| Clear CMOS jumper | Yes |
| BIOS type | UEFI AMI |
| Clear CMOS button | Yes |
| Desktop Management Interface (DMI) version | 2.7 |
| Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Screws included | Yes |
| Antenna included | Yes |
| Batteries included | Yes |
| RAID levels | 1, 10 |
| RAID support | Yes |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 6 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| HDMI version | 2.1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| DisplayPorts quantity | 1 |
| WiFi-AP antenna jack | 2 |
| DisplayPort version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Microphone in | Yes |
| USB 2.0 ports quantity | 2 |
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| 1st M.2 largest key size | 2580 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| Battery type | CR2032 |
| Number of battery cells | 1 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Lithium weight per battery | 0.07 g |
| Weight | 1.3 kg |
| Country of origin | China |
| Products per shipping (inner) case | 1 pc(s) |
| Warnings | Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty. |
