ASUS ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX
Product reference:
6-90MB1CT0-M1EAY0
ASUS ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX
ASUS ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX
Product reference:
6-90MB1CT0-M1EAY0
ASUS ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Europe in
6 - 11
business days
| Compatible processor series | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Processor manufacturer | Intel |
| Maximum number of SMP processors | 1 |
| Processor socket | LGA 1700 |
| Supported processor sockets | LGA 1700 |
| On-board graphics card | No |
| Parallel processing technology support | Not supported |
| Windows operating systems supported | Windows 11, Windows 10 |
| Motherboard chipset family | Intel |
| Cooling type | Passive |
| Motherboard form factor | ATX |
| Power source type | ATX |
| Motherboard chipset | Intel B760 |
| Audio chip | Realtek ALC4080 |
| Product colour | Black |
| Audio output channels | 7.1 channels |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Supported memory clock speed (max) | 7800 MHz |
| ECC сompatibility | Non-ECC |
| Supported memory clock speeds | 6000, 5000, 7800, 6400 MHz, 6800, 7000, 6200, 5200, 6600, 4800 MHz, 5600, 5800, 5400 |
| Maximum internal memory | 192 GB |
| Unbuffered memory | Yes |
| Depth | 244 mm |
| Width | 305 mm |
| Bluetooth version | 5.3 |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Wi-Fi standards | 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11g, 802.11b, Wi-Fi 4 (802.11n) |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| 12V power connector | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| RGB LED pin header | Yes |
| EPS power connector (8-pin) | Yes |
| Front panel audio connector | Yes |
| Number of SATA III connectors | 4 |
| Chassis intrusion connector | Yes |
| Number of chassis fan connectors | 4 |
| Front panel connector | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 2.0 connectors | 2 |
| Thunderbolt headers | 1 |
| BIOS type | UEFI AMI |
| Clear CMOS button | Yes |
| Cables included | SATA |
| User guide | Yes |
| Number of storage drives supported | 7 |
| Number of HDDs supported | 4 |
| RAID support | Yes |
| RAID levels | 5, 10, 1 |
| Supported storage drive interfaces | M.2, SATA III |
| Supported storage drive types | HDD & SSD |
| Headphone outputs | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| WiFi-AP antenna jack | 2 |
| HDMI version | 2.1 |
| Line-in | Yes |
| Microphone in | Yes |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| S/PDIF out port | Yes |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 3 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| Back-to-BIOS button | Yes |
| Warnings | Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal. |
