ASUS PRO Q670M-C-CSM Intel Q670 LGA 1700 micro ATX
Product reference:
6-90MB19E0-M0EAYC
ASUS PRO Q670M-C-CSM Intel Q670 LGA 1700 micro ATX
ASUS PRO Q670M-C-CSM Intel Q670 LGA 1700 micro ATX
Product reference:
6-90MB19E0-M0EAYC
ASUS PRO Q670M-C-CSM Intel Q670 LGA 1700 micro ATX
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Europe in
8 - 12
business days
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Core™ i5, Intel® Celeron®, Intel Pentium G, Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9 |
| Maximum internal memory supported by processor | 128 GB |
| Supported processor sockets | LGA 1700 |
| Processor socket | LGA 1700 |
| Compatible operating systems | Windows® 11 64-bit, Windows® 10 64-bit |
| Audio output channels | 7.1 channels |
| Motherboard form factor | micro ATX |
| Motherboard chipset | Intel Q670 |
| Cooling type | Active |
| Motherboard chipset family | Intel |
| Windows operating systems supported | Windows 10, Windows 11 |
| Number of mounting holes | 8 |
| Power source type | ATX |
| ECC сompatibility | Non-ECC |
| Maximum internal memory | 128 GB |
| Supported memory clock speeds | 4800 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Supported memory module capacities | 32GB, 16GB, 4GB, 8GB |
| Memory channels | Dual-channel |
| Number of memory slots | 4 |
| Height | 51 mm |
| Width | 244 mm |
| Depth | 244 mm |
| Ethernet interface type | Gigabit Ethernet |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 6 |
| CPU fan connector | Yes |
| EPS power connector (8-pin) | Yes |
| Audio connector | Yes |
| USB 2.0 connectors | 2 |
| Number of chassis fan connectors | 2 |
| Number of COM connectors | 2 |
| Cables included | SATA |
| Drivers included | Yes |
| RAID support | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| Supported storage drive types | HDD & SSD |
| RAID levels | 10, 1, 5 |
| Number of HDDs supported | 6 |
| Number of storage drives supported | 8 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 2 |
| PS/2 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Microphone in | Yes |
| HDMI version | 2.1 |
| Headphone outputs | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Weight | 634 g |
| Harmonized System (HS) code | 84733020 |
| Warnings | Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal. |
