Asrock WRX90 WS EVO motherboard AMD WRX90 Socket sTR5 EEB
Product reference:
6-WRX90 WS EVO
Asrock WRX90 WS EVO motherboard AMD WRX90 Socket sTR5 EEB
Asrock WRX90 WS EVO motherboard AMD WRX90 Socket sTR5 EEB
Product reference:
6-WRX90 WS EVO
Asrock WRX90 WS EVO motherboard AMD WRX90 Socket sTR5 EEB
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Europe in
6 - 10
business days
| ATX Power connector (24-pin) | Yes |
| Audio chip | Realtek ALC1220 |
| Audio output channels | 7.1 channels |
| BIOS type | EFI AMI |
| Compatible processor series | AMD Ryzen Threadripper 1000 Series |
| CPU fan connector | Yes |
| Depth | 330 mm |
| DisplayPort version | 1.1a |
| DisplayPorts quantity | 1 |
| ECC сompatibility | ECC |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| IPMI LAN (RJ-45) port | Yes |
| LAN controller | Intel X710-AT2 |
| Maximum internal memory | 2 TB |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | AMD WRX90 |
| Motherboard chipset family | AMD |
| Motherboard form factor | EEB |
| Number of COM connectors | 1 |
| Number of M.2 (M) slots | 2 |
| Number of memory slots | 8 |
| Number of SATA III connectors | 4 |
| Number of storage drives supported | 6 |
| PCI Express x16 (Gen 5.x) slots | 7 |
| Processor manufacturer | AMD |
| Processor socket | Socket sTR5 |
| RAID levels | 1, 10 |
| RAID support | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 7600 |
| Supported memory types | DDR5-SDRAM |
| Supported storage drive interfaces | M.2, SATA III |
| Top Wi-Fi standard | Not available |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2x2 connectors | 1 |
| USB4 Gen 2x2 ports quantity | 2 |
| Warnings | Avoid touching electronic components without proper grounding., Do not dispose of old motherboards in the normal household waste. Return motherboards to an electronic waste collection point., Read the operating instructions carefully before installation. |
| Wi-Fi | No |
| Width | 305 mm |
