Lindy HDMI 8K30 Signal Generator
The HDMI 8K30 Signal Generator is a diagnostic tool designed to test HDMI® signals at maximum 7680x4320@30Hz resolution. It has 13 test patterns, supports HDMI 2.1 with 40Gbps bandwidth, and includes an LCD display for easy operation.
- Generates high-quality HDMI 8K30 test signals for professional AV solutions.
- Supports maximum resolution of 7680x4320 30Hz with 12-bit color depth.
- There are 13 built-in test patterns for detailed signal analysis and diagnostics.
- Compact and durable design with USB-C power and software upgrade capabilities.
Features | |
|---|---|
| Product Type | HDMI Signal Generator |
| Model | HDMI 8K30 Signal Generator |
Specifications | |
| AV Interface | HDMI® |
| Interface Standard | HDMI 2.1 |
| Supported Bandwidth | 40Gbps |
| Maximum Resolution | 7680x4320@30Hz 4:4:4 12bit |
| Color Depth | By 12bit |
| HDCP Support | 2.3 |
| Testing Models | 13 |
| Management | Push button |
| Special Features | LCD display, serial communication |
| Exit | HDMI® Type A (Male) |
| Other Connectors | USB-C (Female) for firmware update and serial communication |
| Power supply | USB-C (Female) |
Physical Properties | |
| Dimensions | 260x48x19mm (10.24x1.89x0.75in) |
| Housing | Metal |
| Net Weight | 0.19kg (0.42lb) |
| Operating Temperature | -5°C - 55°C (23°F - 131°F) |
| Storage Temperature | -20°C - 70°C (-4°F - 158°F) |
| Humidity | 0%~80%RH (non-condensing) |
| Power Requirements | 5V 1A |
| Color | Black |
Package Contents | |
| Included Items |
|
www.lindy.lt
| Height | 50mm |
| Length | 300mm |
| Weight | 370g |
| Width | 150mm |
