HDMI Signal Analyzer - Lindy 32695 8K60 40Gbps
Product reference:
14-4002888326957
The HDMI 8K60 Signal Analyzer is a diagnostic tool for testing HDMI® AV signals, supporting resolutions up to 8K60Hz and bandwidths up to 40Gbps. It features an LCD display, button controls, and support for a variety of audio formats, including Dolby Atmos® and DTS:X.
HDMI Signal Analyzer - Lindy 32695 8K60 40Gbps
Product reference:
14-4002888326957
The HDMI 8K60 Signal Analyzer is a diagnostic tool for testing HDMI® AV signals, supporting resolutions up to 8K60Hz and bandwidths up to 40Gbps. It features an LCD display, button controls, and support for a variety of audio formats, including Dolby Atmos® and DTS:X.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Lindy HDMI 8K60 Signal Analyzer Professional Diagnostic Tool
The HDMI 8K60 Signal Analyzer is a diagnostic tool for testing HDMI® AV signals, supporting resolutions up to 8K60Hz and bandwidths up to 40Gbps. It features an LCD display, button controls, and supports a variety of audio formats, including Dolby Atmos® and DTS:X.
- Professional HDMI signal analyzer for diagnosing and troubleshooting HDMI 2.1 connections.
- Supports high 40Gbps bandwidth and maximum 8K resolution 60Hz, ensuring advanced image quality.
- Equipped with an LCD screen for real-time monitoring of signal parameters and audio formats.
- Compact and durable metal housing, designed for reliable operation in a variety of environments.
Features | |
|---|---|
| Product Type | HDMI Signal Analyzer |
| Product Brand | Lindy |
| Model | HDMI 8K60 Signal Analyzer |
Specifications | |
| AV Interface | HDMI® |
| Interface Standard | HDMI 2.1 |
| Supported Bandwidth | 40Gbps |
| Maximum Resolution | 8K60Hz 4:2:0 10-bit |
| Color Depth | to 12bit |
| HDCP Support | 2.3 |
| Audio Formats | LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital® Plus, DTS:X, DTS-HD® Master Audio |
| Management | Button Control |
| Special Features | LCD display, serial communication |
Connectors | |
| Input | HDMI® Type A (Male) |
| Other Connectors | USB-C (Female) for firmware update and serial communication |
| Power supply | USB-C (Female) |
Physical Properties | |
| Dimensions | 260x48x19mm (10.24x1.89x0.75in) |
| Housing Material | Metal |
| Net Weight | 0.19kg (0.42lb) |
| Operating Temperature | -5°C - 55°C (23°F - 131°F) |
| Storage Temperature | -20°C - 70°C (-4°F - 158°F) |
| Humidity | 0%~80%RH (non-condensing) |
| Power Requirements | 5V 1.5A |
| Color | Black |
www.lindy.lt
| Height | 50mm |
| Length | 300mm |
| Weight | 290 g |
| Width | 150mm |
