Camera monitor - Feelworld L7S 7″ 2200 nits touch monitor
Product reference:
14-8718485919060
The 7-inch Full HD touch monitor features 2,200 nits of brightness, 4K HDMI and 3G-SDI inputs, and a sunlight-readable display. It is equipped with two " Sony F970 " battery holders, waveform and vector area meters, 3D LUT support, HDR monitoring, and HDMI/SDI signal transmission outputs.
Camera monitor - Feelworld L7S 7″ 2200 nits touch monitor
Product reference:
14-8718485919060
The 7-inch Full HD touch monitor features 2,200 nits of brightness, 4K HDMI and 3G-SDI inputs, and a sunlight-readable display. It is equipped with two " Sony F970 " battery holders, waveform and vector area meters, 3D LUT support, HDR monitoring, and HDMI/SDI signal transmission outputs.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Feelworld L7S 7" 2200 nits touch monitor
7-inch Full HD touch monitor with 2200 nits brightness, 4K HDMI and 3G-SDI inputs, and a sunlight-readable display. It features two " Sony F970 " battery slots, waveform and vectorscope functions, 3D LUT support, HDR monitoring, and HDMI/SDI loop outputs.
- 7-inch Full HD IPS touchscreen, 1920 × 1200 pixel resolution and ultra-high 2200 nits brightness, ensuring clear viewing in direct sunlight
- Supports 4K HDMI and 3G-SDI inputs with loop-through outputs, allowing for connection of various cameras and external monitors
- Professional monitoring tools: 3D LUT support, HDR, waveform, vectorscope, RGB histogram and focus assist
- Flexible control and power: touch screen or physical buttons, two " Sony F970 " battery slots and 12V DC input
Product information | |
|---|---|
| Product type | Professional camera monitor |
| Brand | Feelworld |
| Model | L7S |
| Screen type | 7 inch IPS LCD touch screen |
| Housing material | Aluminum |
Display specifications | |
| Resolution | 1920 × 1200 pixels |
| Brightness | 2200 cd/m² |
| Viewing angle | 160° |
| Color standard | Rec.709 and ITU-compatible color space |
| Brightness control | Automatic adjustment using ambient light sensor |
Monitoring functions | |
| LUT support | 3D LUT support, including conversion from log to Rec.709 and loading up to 50 user LUTs |
| HDR monitoring | Supported |
| Image analysis | Waveform, vectorscope and RGB histogram |
| Focus and image assist functions | Focus assist, monochrome display and other observation tools |
| Management | Touchscreen, physical buttons and control wheel; configurable F1-F3 quick action buttons |
| Touchscreen lock | The touch function can be disabled to prevent accidental operation |
Communications and sound | |
| HDMI | 4K HDMI input with loop-through output |
| SDI | 3G-SDI input with loop output |
| SDI LUT output | Supports 3G-SDI loop output with customized LUT |
| Headphone output | 3.5 mm stereo headphone jack |
| Wireless monitoring | Compatible with wireless video transmitters connected to video inputs |
Power supply | |
| Battery sockets | Two " Sony F970 " type battery slots |
| Compatible battery series | " Sony " F970, F960, F950, F930, F770, F750, F730, F570, F550 and F530 series |
| DC input | 12 V DC |
Safety information | |
| Safety warning | Use the monitor for camera and video surveillance purposes only. Use compatible batteries and a suitable 12V DC power supply. Protect the monitor from moisture, ensure adequate ventilation, and do not use it if the housing, power input, or cables are damaged. |
| Height | 70 mm |
| Length | 320mm |
| Weight | 1200g |
| Width | 220mm |
