Zyxel GS1920-24HPV2-EU0101F
Product reference:
3-4718937601936
Zyxel GS1920-24HPV2-EU0101F
Zyxel GS1920-24HPV2-EU0101F
Product reference:
3-4718937601936
Zyxel GS1920-24HPV2-EU0101F
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 8
business days
| Design | |
|---|---|
| Certification | RoHS |
| Product colour | Black |
| LED indicators | Yes |
| Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
| Rack mounting | Yes |
| Safety | LVD, BSMI |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240V |
| Power consumption (max) | 463.5W |
| Security | |
| Security algorithms | SNMPv3, SNMP, 802.1x RADIUS |
| MAC address filtering | Yes |
| Authentication type | IEEE 802.1x, RADIUS |
| IGMP snooping | Yes |
| DHCP features | DHCP client, DHCP relay, DHCPv6 relay, DHCP snooping |
| IP-MAC-Port binding | Yes |
| Password protection | Yes |
| CPU defense | Yes |
| Access Control List (ACL) | Yes |
| Queue scheduling algorithms | WFQ, SPQ, Weighted Round Robin (WRR) |
| Authentication | Guest VLAN, Port-based authentication |
| Operational conditions | |
| Operating relative humidity (HH) | 10 - 95% |
| Storage relative humidity (HH) | 10 - 95% |
| Operating temperature (TT) | 0 - 50 °C |
| Heat dissipation | 1580.54 BTU/h |
| Storage temperature (TT) | -40 - 70 °C |
| Management features | |
| ARP inspection | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Weight dimensions | |
| Weight | 3.8 kg |
| Width | 441 mm |
| Height | 44 mm |
| Depth | 270mm |
| Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3at, IEEE 802.3af, IEEE 802.3ad, IEEE 802.1s 802.1D, IEEE 802.1x, IEEE 802.1ab, IEEE 802.3z |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Virtual LAN features | IP subnet-based VLAN, MAC address-based VLAN, Private VLAN, Voice VLAN, Port-based VLAN, Protocol-based VLAN |
| VLAN support | Yes |
| Copper ethernet cabling technology | 100BASE-TX, 1000BASE-T |
| 10G support | From |
| Flow control support | Yes |
| Performance | |
| Noise level | 27.2 dB |
| Mean time between failures (MTBF) | 638691 hours |
| Internal memory | 256MB |
| Flash memory | 32MB |
| Packaging data | |
| Package width | 616 mm |
| Package height | 107 mm |
| Cables included | AC |
| Package weight | 4.97 kg |
| Rack mount kit | Yes |
| Package depth | 355mm |
| Ports interfaces | |
| Fiber optic connector | SFP |
| Basic switching RJ-45 Ethernet port type | Gigabit Ethernet (10/100/1000) |
| Combo SFP port quantity | 4 |
| Basic switching RJ-45 Ethernet port quantity | 24 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Data transmission | |
| Forwarding rate | 42 Mpps |
| Switching capacity | 56 Gbps |
| MAC address table | 16000 entries |
| Packet buffer memory | 1.5MB |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) port quantity | 24 |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 375W |
| Multicast features | |
| Multicast support | Yes |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
