TP-LINK TPLINK Switch TL-SG1218MPE TLSG1218MPE (TL-SG1218MPE)
Product reference: 3-6935364086923

TP-LINK TPLINK Switch TL-SG1218MPE TLSG1218MPE (TL-SG1218MPE)

TP-LINK TPLINK Switch TL-SG1218MPE TLSG1218MPE (TL-SG1218MPE)

Product reference: 3-6935364086923

TP-LINK TPLINK Switch TL-SG1218MPE TLSG1218MPE (TL-SG1218MPE)

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
203,63
209,93 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 8
business days

Your message has been successfully sent!
Fill in the required fields*

Ideal for Surveillance
TL-SG1218MPE complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget is up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.

Intelligent Power Management
When total power consumption excels 192W, the intelligent power management will cut the lower priority port power off to ensure the high priority port's power supply and protect the device from power overload operation.

Making Management Easy
TL-SG1218MPE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG1218MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.

  • 16 10/100/1000Mbps RJ45 POE+ Ports Switch
  • PoE power budget is up to 192W, making it ideal for small to medium business surveillance systems
  • Port Priority is able to guarantee the quality of sensitive application like video monitor
  • Intelligent power management can protect the switch from overload
  • QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV

Summary: TP-Link JetStream 16-Port Gigabit Easy Smart PoE/PoE+ Switch. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 36 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Vendor Homepage: https://www.tp-link.com/ae/business-networking/easy-smart-switch/tl-sg1218mpe/
Category Code: SWI
CnCode: 85176200
Unit Box Height: 0.08
Unit Box Length: 0.53
Unit Box Width: 0.25
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Web-based management: Yes
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 16
SFP module slots quantity: 2
10G support: No
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Broadcast storm control: Yes
Cable types supported: Cat3/Cat4/Cat5/Cat5e/Cat6
Copper ethernet cabling technology: 1000BASE-T/100BASE-TX/10BASE-T
Flow control support: Yes
Link aggregation: Yes
Networking standards: IEEE 802.1p/IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u/IEEE 802.3x
Number of VLANs: 32
Port mirroring: Yes
Rate limiting: Yes
Virtual LAN features: Port-based VLAN
VLAN support: Yes
Fiber ethernet cabling technology: 1000BASE-X
Forwarding rate: 23.8Mpps
Jumbo frames: 9000
Jumbo frames support: Yes
MAC address table: 8000entries
Number of queues: 4
Packet buffer memory: 4.1MB
Store-and-forward: Yes
Switching capacity: 36Gbit/s
IGMP snooping: Yes
Loop protection: Yes
Security algorithms: SNMP/SNMPv2/SNMPv3
Form factor: 1U
Number of fans: 2fan(s)
Product colour: Black
Rack mounting: Yes
AC input frequency: 50 - 60Hz
AC input voltage: 100 - 240V
Power consumption (max): 217.22W
Power source: AC
Power supply included: Yes
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 16
Total Power over Ethernet (PoE) budget: 192W
Heat dissipation: 741.15BTU/h
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50°C
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70°C
Depth: 180mm
Height: 44mm
Width: 440mm
Cables included: AC
Rack mount kit: Yes
User guide: Yes
Package depth: 528mm
Package height: 80mm
Package weight: 2910g
Package width: 250mm
Certification: CE, FCC, RoHS
Harmonized System (HS) code: 85176990
Model name: JetStream 16-Port Gigabit Easy Smart PoE/PoE+ Switch
Units per Shipping Box: 1
Unit Calculated Volume: 0.0106m³
Unit Calculated Weight: 3.11kg
