TP-LINK TPLINK Switch Omada Agile (SL2428P)
Product reference:
3-6935364030612
TP-LINK TPLINK Switch Omada Agile (SL2428P)
TP-LINK TPLINK Switch Omada Agile (SL2428P)
Product reference:
3-6935364030612
TP-LINK TPLINK Switch Omada Agile (SL2428P)
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 8
business days
TP-Link's brand new Omada smart switches provide a huge upgrade compared to previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
- 24× 10/100 Mbps 802.3af/at PoE+ port with up to 30 W PoE output per port
- 2× Gigabit RJ45 ports and 2× Combo Gigabit RJ45/SFP ports
- 250 W total PoE budget
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, and IGMP Snooping
- Durable metal casing and rackmountable design
| Summary: | TP-Link Omada SL2428P. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 12.8 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE... Power over Ethernet (PoE). Rack mounting, Form factor: 1U |
| Vendor Homepage: | https://www.tp-link.com/en/business-networking/omada-switch-poe/sl2428p/#overview |
| Category Code: | SWI |
| CnCode: | 85176200 |
| Unit Box Height: | 0.08 |
| Unit Box Length: | 0.535 |
| Unit Box Width: | 0.252 |
| ARP inspection: | Yes |
| Configuring Location Settings (CLI): | Yes |
| Quality of Service (QoS) support: | Yes |
| Switch layer: | L2 |
| Switch type: | Managed |
| System event log: | Yes |
| Web-based management: | Yes |
| Basic switching RJ-45 Ethernet port quantity: | 24 |
| Basic switching RJ-45 Ethernet port type: | Fast Ethernet (10/100) |
| Combo SFP ports quantity: | 2 |
| Fast Ethernet (copper) port quantity: | 24 |
| Gigabit Ethernet (copper) port quantity: | 4 |
| 10G support: | From |
| Auto MDI/MDI-X: | Yes |
| Broadcast storm control: | Yes |
| Cable types supported: | Cat5/Cat5e |
| Copper ethernet cabling technology: | 1000BASE-T/100BASE-TX/10BASE-T |
| Flow control support: | Yes |
| Link aggregation: | Yes |
| Networking standards: | IEEE 802.1D/IEEE 802.1p/IEEE 802.1Q/IEEE 802.1s/IEEE 802.1w/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x |
| Number of VLANs: | 512 |
| Port mirroring: | Yes |
| Rate limiting: | Yes |
| Spanning tree protocol: | Yes |
| VLAN support: | Yes |
| Jumbo frames: | 9000 |
| Jumbo frames support: | Yes |
| MAC address table: | 8000entries |
| Number of queues: | 4 |
| Packet buffer memory: | 4.1MB |
| Switching capacity: | 12.8Gbit/s |
| Throughput: | 9.5Mpps |
| Access Control List (ACL): | Yes |
| IGMP snooping: | Yes |
| Security algorithms: | SNMPv2/SNMPv3/SSH/SSH-2/SSL/TLS |
| SSH/SSL support: | Yes |
| Multicast support: | Yes |
| Management protocols: | SNMP v1/v2c/v3, RMON, SNTP, TFTP |
| Form factor: | 1U |
| Number of fans: | 2fan(s) |
| Product colour: | Black |
| Rack mounting: | Yes |
| Compatible operating systems: | Microsoft Windows XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
| Firmware upgradeable: | Yes |
| AC input frequency: | 50/60Hz |
| AC input voltage: | 100 - 240V |
| Power consumption (max): | 291.6W |
| Power source: | AC |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet plus (PoE+) port quantity: | 24 |
| Total Power over Ethernet (PoE) budget: | 250W |
| Heat dissipation: | 995.09BTU/h |
| Operating relative humidity (HH): | 10 - 90% |
| Operating temperature (TT): | 0 - 40°C |
| Storage relative humidity (HH): | 5 - 90% |
| Storage temperature (TT): | -40 - 70°C |
| Depth: | 180mm |
| Height: | 44mm |
| Width: | 440mm |
| Cables included: | AC |
| Quick start guide: | Yes |
| Rack mount kit: | Yes |
| Certification: | CE, FCC, RoHS |
| Model name: | SL2428P |
| Units per Shipping Box: | 1 |
| Unit Calculated Volume: | 0.01079m³ |
| Unit Calculated Weight: | 3.2kg |
