Tenda TEG2208D Websmart L2 cloud managed switch, 8x 10 / 100 / 1000 Mbps, Kov, Fanless - bez ventilátorů

Standartyprotokoly: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.1p, IEEE802.1q
LED Indication: 8x Link/Act, 2x PWR/SYS LED
Porty: 8x 10/100/1000 Base-T
Level protection: - pro porty: 6kV, - power supply: 6kV
Switching mode: Store-and-forward
Total throughput: 16 Gbps
Switching packets: 11,9Mpps
Buffer: 4MB
Size tables MAC address: 8K
Power supply: ze sítě 100-240V AC 50/60Hz
Device dimensions: 140mm x 66mm 25mm(L*W*H)
Working temperature: 0oC ~ 45oC
Vlhkost: 10%-90%RH (non-condensing)
Certification: CE/RoHS
Security features:
- Support whitelist binding of MAC addresses, ports and VLAN,
- Support port isolation
VLAN:
- Support VLAN transparent transmission,
- Support IEEE 802.1Q VLAN,
DHCP:
- Support DHCP Client,
- Support DHCP Snooping,
IGMP:
- Supports IGMP fast leave,
- Support IGMP Report Suppression
QoS:
- Support DSCP priority,
- Support SP, SWP, WP,
Port properties:
- Support port flow control,
- Support port isolation,
- Support N:1 port mirroring,
- Support ports statistics of received and transmitted packets, conflict packets and CRC error packets
Rate limit:
- Support ingress and egress rate limits on ports
Loop guard:
- Support loop detection and guard on each port
Storm control:
- Support storm control on ports
Upgrade, import, export:
- Support HTTP upgrade and configuration import/export
Management and maintenance:
- Support CloudFi App management,
- Support Cloud web UI management,
- Support local web UI management,
- Support ping test
Product details
Tenda TEG2208D presents a very convenient local nebo cloudové setup incl.
Flexible QoS, precise control of data traffic
TEG2208D supports three QoS scheduling modes (SP, SWP, WP) for more accurate traffic control. Po povolení funcze QoS bude provoz v síti zače řízen podle priority dat.
Management
Supports the use of standard web local management, nebo is also available cloud web management and also CloudiFi application for mobile devices.
Network topology display
Switch supports automatic search and display topology networks.
Safety
The switch controls network settings in real time, supports DHCP Snooping, Loop Guard, Storm control, 7/24 Watchdog and more.
Package contents
1x Tenda TEG2208D
1x Expert installation manual (CZ, SK, PL, EN)
1x Power supply adapter
