The SWM282 is a high-capacity L2 managed switch with enhanced L3 capabilities, built to simplify network control while delivering power and connectivity at scale. It features 24 PoE+ ports, supplying up to 30 W per port with a total power budget of 300 W, and 4 SFP ports. With support for PROFINET and other industrial protocols, this 24-port switch is an ideal choice for enterprise networks and IIoT solutions.
| Summary: | Teltonika SWM282 . Switch type: Managed, Switch layer: L2 +. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1x, IEEE 802.3af, IEEE.... Power connector: AC -in jack. Power over Ethernet (PoE). Rack mounting |
| Vendor Homepage: | https://www.teltonika-networks.com/products/ethernet-switches/swm282 |
| Category Code: | SWI |
| CnCode: | 85176200 |
| Unit Box Height: | 0.1 |
| Unit Box Length: | 0.52 |
| Unit Box Width: | 0.33 |
| Quality of Service (QoS) support: | Yes |
| Switch layer: | L2 + |
| Switch type: | Managed |
| Traffic shaping: | Yes |
| Web-based management: | Yes |
| Basic switching RJ-45 Ethernet port quantity: | 24 |
| Basic switching RJ-45 Ethernet port type: | Gigabit Ethernet (10/100/1000) |
| Power connector: | AC -in jack |
| SFP module slots quantity: | 4 |
| 10G support: | From |
| Auto MDI/MDI-X: | Yes |
| Ethernet LAN data rates: | 10,100,1000Mbit/s |
| Networking standards: | 802.3x 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3i/IEEE 802.3u/IEEE |
| Port mirroring: | Yes |
| Rate limiting: | Yes |
| VLAN support: | Yes |
| Forwarding rate: | 83.33Mpps |
| Jumbo frames: | 10000 |
| Jumbo frames support: | Yes |
| MAC address table: | 8000entries |
| Packet buffer memory: | 0.512MB |
| Static route: | Yes |
| Switching capacity: | 56Gbit/s |
| Authentication type: | RADIUS,TACACS+ |
| DHCP features: | DHCP client/DHCP server/DHCPv6 client |
| Loop protection: | Yes |
| MAC address filtering: | Yes |
| Queue scheduling algorithms: | SP/Weighted Round Robin (WRR)/WFQ |
| Housing material: | Aluminum |
| International Protection (IP) code: | IP30 |
| Product color: | Black |
| Rack mounting: | Yes |
| Reset button: | Yes |
| Built-in processor: | Yes |
| Firmware upgradeable: | Yes |
| Flash memory: | 16MB |
| Internal memory: | 128MB |
| Memory type: | DDR3-SDRAM |
| Processor frequency: | 500MHz |
| AC input frequency: | 50/60Hz |
| AC input voltage: | 100 - 240V |
| Power consumption (max): | 330W |
| Power source: | AC |
| Power supply included: | From |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet (PoE) modes: | Alternative A |
| Power over Ethernet (PoE) power per port: | 30W |
| Power over Ethernet (PoE) type supported: | Active PoE/PoE+ |
| Power over Ethernet plus (PoE+) port quantity: | 24 |
| Total Power over Ethernet (PoE) budget: | 300W |
| Operating relative humidity (HH): | 10 - 90% |
| Operating temperature (TT): | 0 - 50°C |
| Depth: | 234mm |
| Height: | 44mm |
| Weight: | 2291g |
| Width: | 483mm |
| Quick start guide: | Yes |
| Package type: | Box |
| Compliance certificates: | CB/CE/Federal Communications Commission (FCC)/Industry Canada (IC)/RCM/UKCA |
| Model: | SWM282 |
| Model name: | SWM282000200 |
| Units per Pallet: | 0 |
| Units per Shipping Box: | 1 |
| Unit Calculated Volume: | 0.01716m³ |
| Unit Calculated Weight: | 2.58kg |
