Switch ZyXEL XGS2220-54FP (XGS2220-54FP-EU0101F)
Product reference:
3-4718937625130
Switch ZyXEL XGS2220-54FP (XGS2220-54FP-EU0101F)
Switch ZyXEL XGS2220-54FP (XGS2220-54FP-EU0101F)
Product reference:
3-4718937625130
Switch ZyXEL XGS2220-54FP (XGS2220-54FP-EU0101F)
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
9 - 14
business days
| Design | |
|---|---|
| Rack mounting | Yes |
| Power | |
| Power source | AC |
| AC input frequency | 50 - 60 Hz |
| Power supply included | Yes |
| Power consumption (max) | 1161.6 W |
| AC input voltage | 100 - 240 V |
| Security | |
| IGMP snooping | Yes |
| DHCP features | DHCP server, DHCP relay |
| Authentication type | IEEE 802.1x, RADIUS, TACACS+ |
| IGMP proxy | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 195.43 BTU/h |
| Operating temperature (T-T) | -20 - 50 °C |
| Management features | |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Switch layer | L3 |
| Weight & dimensions | |
| Width | 441 mm |
| Depth | 330 mm |
| Weight | 5 kg |
| Height | 44 mm |
| Network | |
| Networking standards | IEEE 802.1ab, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3at, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3an, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x |
| 10G support | Yes |
| Routing entries | 64 |
| Performance | |
| Mean time between failures (MTBF) | 298.735 h |
| Internal memory | 1024 MB |
| Flash memory | 64 MB |
| Protocols | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| 10G Ethernet (copper) ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Installed SFP+ modules quantity | 4 |
| Data transmission | |
| MAC address table | 32000 entries |
| Switching capacity | 216 Gbit/s |
| Forwarding rate | 161 Mpps |
| Packet buffer memory | 2 MB |
| Jumbo frames support | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 50 |
| Total Power over Ethernet (PoE) budget | 960 W |
| Multicast features | |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 |
