Switch Pro XG 10 POE Managed Switch USW-Pro-XG-10-PoE
Product reference:
3-810177160137
Switch Pro XG 10 POE Managed Switch USW-Pro-XG-10-PoE
Switch Pro XG 10 POE Managed Switch USW-Pro-XG-10-PoE
Product reference:
3-810177160137
Switch Pro XG 10 POE Managed Switch USW-Pro-XG-10-PoE
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
9 - 14
business days
1U, professional-grade 10-port, Layer 3 Etherlighting™ PoE+++ switch with (10) 10 GbE and (2) 10G SFP+ ports.
| Summary: | Ubiquiti UniFi Pro XG 10 PoE. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 32000 entries, Switching capacity: 240 Gbit/s. Power connector: AC/DC. Power over Ethernet (PoE). Rack mounting, Form factor: 1U |
| Vendor Homepage: | https://eu.store.ui.com/eu/en/category/switching-professional-max-xg/products/usw-pro-xg-10-poe |
| Category Code: | SWI |
| CnCode: | 85176200 |
| Unit Box Height: | 0.39 |
| Unit Box Length: | 0.52 |
| Unit Box Width: | 0.12 |
| Switch type: | Managed |
| Switch layer: | L2/L3 |
| Quality of Service (QoS) support: | Yes |
| Basic switching RJ-45 Ethernet ports quantity: | 10 |
| Basic switching RJ-45 Ethernet ports type: | 10G Ethernet (100/1000/10000) |
| 10G Ethernet (copper) ports quantity: | 10 |
| SFP+ module slots quantity: | 2 |
| Power connector: | AC/DC |
| 10G support: | Yes |
| Port mirroring: | Yes |
| Broadcast storm control: | Yes |
| Flow control support: | Yes |
| IPv4 routes: | 12000 |
| Rate limiting: | Yes |
| VLAN support: | Yes |
| Virtual LAN features: | Interface-based VLAN/Voice VLAN |
| Number of VLANs: | 1000 |
| Switching capacity: | 240Gbit/s |
| Throughput: | 120Gbit/s |
| Forwarding rate: | 179Mpps |
| MAC address table: | 32000entries |
| Static route: | Yes |
| Jumbo frames support: | Yes |
| Packet buffer memory: | 2MB |
| DHCP features: | DHCP guarding/DHCP relay/DHCP server/DHCPv6 snooping |
| IGMP snooping: | Yes |
| Loop protection: | Yes |
| Multicast support: | Yes |
| Rack mounting: | Yes |
| Stackable: | Yes |
| Form factor: | 1U |
| Product colour: | Grey |
| Housing material: | SGCC |
| Reset button: | Yes |
| LED indicators: | System |
| Backlight display: | Yes |
| Display type: | LCM |
| Power source: | AC/DC |
| Power supply included: | Yes |
| Redundant power supply (RPS) support: | Yes |
| AC input voltage: | 100 - 240V |
| AC input frequency: | 50/60Hz |
| Power consumption (max): | 520W |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet (PoE) type supported: | PoE++ (4PPoE) |
| Power over Ethernet 4PPoE (PoE++) ports quantity: | 10 |
| Power over Ethernet (PoE) power per port: | 15.4W |
| Total Power over Ethernet (PoE) budget: | 400W |
| Operating temperature (T-T): | -5 - 40°C |
| Operating relative humidity (H-H): | 10 - 90% |
| Width: | 442.4mm |
| Depth: | 285mm |
| Height: | 44mm |
| Weight: | 4600g |
| Cables included: | Power |
| Manual: | Yes |
| Rack mount kit: | Yes |
| Compliance certificates: | CE/Federal Communications Commission (FCC)/Industry Canada (IC)/National Defense Authorization Act (NDAA) |
| Unit Calculated Weight: | 6.25kg |
| Product Net Weight: | 4.6kg |
| Unit Calculated Volume: | 0.02894m³ |
| Units per Shipping Box: | 2 |
| Shipping Box Weight: | 12.5kg |
| Unit Width: | 12cm |
| Units per Pallet: | 0 |
| Shipping Box Height: | 42cm |
| Unit Depth: | 52cm |
| Shipping Box Depth: | 53cm |
| Unit Height: | 39cm |
| Shipping Box Width: | 26cm |
| Name: | NET SWITCH PRO XG 10 POE/USW-PRO-XG-10-POE UBIQUITI |
| Model: | USW-PRO-XG-10-POE |
