DIN RAIL SWITCH
TSW304 is the tiniest switch in the Teltonika Networks portfolio, made with the industrial application scenarios in mind. This ultra-small device comes with an integrated DIN rail mounting option and will easily find its place in any server cabinet. Durable design and shock-resistant casing make it perfect for even the most challenging industrial environments.
MOUNTING
Integrated DIN rail bracket and surface mounting options
COMPACT
102 x 25 x 81.5 mm
GIGABIT ETHERNET
4 x Gigabit Ethernet with speeds of up to 1000 Mbps
7-57V
Wide range of supported power supply voltages
| Summary: | Teltonika TSW304. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4. MAC address table: 2000 entries, Switching capacity: 8 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u. DC input voltage: 7 - 57 V. Power over Ethernet (PoE). Wall mountable |
| Vendor Homepage: | https://teltonika-networks.com/products/switches/tsw304 |
| Category Code: | SWI |
| CnCode: | 85176200 |
| Unit Box Height: | 0.03 |
| Unit Box Length: | 0.1 |
| Unit Box Width: | 0.11 |
| Basic switching RJ-45 Ethernet port quantity: | 4 |
| Basic switching RJ-45 Ethernet port type: | Gigabit Ethernet (10/100/1000) |
| 10G support: | From |
| Auto MDI/MDI-X: | Yes |
| Ethernet LAN data rates: | 10,100,1000Mbit/s |
| Networking standards: | IEEE 802.3/IEEE 802.3az/IEEE 802.3u |
| Jumbo frames: | 9216 |
| Jumbo frames support: | Yes |
| MAC address table: | 2000entries |
| Packet buffer memory: | 0.128MB |
| Switching capacity: | 8Gbit/s |
| DIN rail mounting: | Yes |
| Housing material: | Aluminum |
| International Protection (IP) code: | IP30 |
| LED indicators: | Power/Status |
| Product colour: | Black |
| Wall mountable: | Yes |
| DC input voltage: | 7 - 57V |
| Input voltage: | 9 - 40V |
| Power consumption (max): | 1.44W |
| Power consumption (typical): | 0.26W |
| Power source: | AC/DC |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet (PoE) type supported: | Passive PoE |
| Operating relative humidity (HH): | 10 - 90% |
| Operating temperature (TT): | -40 - 75°C |
| Depth: | 81.5mm |
| Height: | 25mm |
| Weight: | 210g |
| Width: | 102mm |
| Certification: | CE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM |
| Model: | TSW304 |
| Model name: | TSW304 |
| Units per Pallet: | 0 |
| Units per Shipping Box: | 1 |
| Unit Calculated Volume: | 0.00033m³ |
| Unit Calculated Weight: | 0.23kg |
