Switch gerezalny Tenda TEG2220P-16-250W 18GE+2SFP PoE 250W

Sposoby umistenenia: do racku (rackmount), na stenu, desktop
Standarby a protokoly: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3z, IEEE802.3x, IEEE802.1p, IEEE802.1q_
LED Indikácia: 18x Link/Act, 3x PWR/SYS/PoE max LED_
Porty: 16x 10/100/1000 Base-T (PoE + data), 2x 10/100/1000 Base-T (data), 2x 1000 Base-X SFP
Level of surge protection: - pre port: 6kV, - pre napájanie: 6kV
Prepínania mode: Store-and-forward
Total bandwidth: 40 Gbps
Prepínanie paketov: 29,8Mpps
MTBF: 50,000+ hod.
Size tables MAC adries: 8K
Power supply: zo siete 100-240V AC 50/60Hz
Size devices: 440mm x 178mm x 44mm(L*W*H)
Working temperature: 0oC ~ 45oC
Temperature: 10%-90%RH (non-condensing)
Certification: CE/RoHS
VLAN:
- Support VLAN transparent transmission,
- Support IEEE 802.1Q VLAN,
Port properties:
- Support port flow control,
- Support port isolation,
- Support N:1 port mirroring,
- Support ports statistics of received and transmitted packets, conflict packets and CRC error packets
Speed limit:
- Support port entrance and exit speed limit
Anti-ring / Loop guard:
- Support switch port loop protection
QoS:
- Support strict priority,
- Supports weighted priority,
MAC:
- Support MAC address table viewing
- MAC whitelist binding
Storm control:
- Support storm control on ports
Upgrade, import, export:
- Support HTTP upgrade and configuration import/export
IGMP:
- Supports IGMP fast leave,
- Support IGMP Report Suppression
DHCP:
- Support DHCP Client,
- Support DHCP Snooping,
PoE:
- Support PoE power display
- Support PoE on and off
- Support PoE timing
Watchdog:
- 7/24 hours automatic operation and maintenance
Management and maintenance:
- Support CloudFi App management,
- Support Cloud web UI management,
- Support local web UI management,
- Support ping test
Product details
Tenda TEG2220P-16-250W presents a very convenient local or cloud setup including advanced network functions, controls, protection, restrictions, etc.
PoE power supply
Uses a built-in power supply with a maximum output power of 230 W for PoE devices. The switch automatically activates/deactivates the PoE power supply of the end device during working hours or when setting the timer in order to minimize energy consumption and extend the life of the end device.
PoE support according to the standard 802.3af (15,4W) a 802.3at (30W). If it is possible to combine different types of power so that it is max. odber 230W. Very detailed PoE management allows switching on/off PoE separately for each port, so you can remotely restart/switch on/off each PoE device separately. Switch má zataženia PoE pre kadzi port.
Flexible QoS, precise management of data traffic
TEG2220P-16-250W supports three QoS scheduling modes (SP, SWP, WP) for more accurate traffic control. After enabling the QoS function, the operation of the network will be precisely controlled by priority data.
Management
Supports the use of standard web local management, or cloud web management is also available, as well as the CloudiFi application for mobile devices.
Network topology display
Switch supports automatic search and display topology siete.
Safety
In real time, the switch controls network settings, supports DHCP Snooping, Loop Guard, Storm control, 7/24 Watchdog and more.
Placement methods
Switch supports 19" rack mounting, also wall mounting, as well as standard desktop placement.
Package contents
1x Tenda TEG2220P-16-250W
1x rack/wall mounts
1x Quick Installation Guide (CZ, SK, PL, EN)
1x Napájací kabel
Viac informació na www.tenda.cz
