SF1016 switch L2 16x10 / 100 Desktop / Rack

B TL-SF1016 16-port 10/100 Mbps rack switch, greenB
B OVERVIEWB
* Innovative energy-saving technology reduces consumption by up to 40%
* 100% data filtering eliminates all bad packets
* Supports control flow IEEE 802.3x for full duplex mode and Backpressure for half duplex mode
* Unrestricted compression architecture transmits filtered packets at full speed in the cable, ensuring maximum throughput
* Uplink capacity 3.2 Gbit/s
* The Auto MDI/MDIX function eliminates the need for cross cables
* Supports automatic learning of MAC addresses and Auto-aging
* Podporuje automatic vyjendanie N-Way, ulačadán a odovzdávanie
* Compact dimensions designed for desktop computers, rack mounting
* Plug and Play design makes installation easy
SPECIFICATIONS
HARDWARE FUNCTIONS
Standards and protocols
* IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Storage
* 16 ports 10/100 Mbit/s RJ45
* Automatic negotiation/AUTO MDI/MDIX
Network media
* 10BASE-T: UTP category 3, 4, 5 cable (maximálne 100 m)
* 100BASE-TX: UTP category 5, 5e or higher cable (maximálne 100 m)
External power supply
* Input: 220-240 VAC, 50/60 Hz Output: 12 VDC/2.0 A
Number of fans
* Without fan
Power supply
* 100-240VAC, 50/60Hz
Dimensions (w*h*h)
* 440*180*44mm
Spotreba
* Maximálna: 2.23 W (220 V/50 Hz)
* PERFORMANCE
Switching Capacity
* 3.2Gbps
MAC address table
* 8K
Buffer Memory
* 2Mb
Packet transmission speed
* 2.38 Mpps
Green technology
* Innovative energy-saving technology saves up to 70% energy
Transmission method
* Store-and-Forward
SOFTWARE FUNCTIONS
Transmission method
* Save and send
MAC address table
* 8,000
Advanced features
* Riadenie toku 802.3X, Backpressure
* Automatic sending to every port
OTHER
Certification
* FCC, CE, RoHS
Package contents
* TL-SF1016
* Power cable
* User manual
System requirements
* Microsoft® Windows® 8, 7, Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux.
Operating environment
* Prevádzková temperature: 0-40 °C;
* Temperature during operation: -40-70 °C;
* Prevádzková humidity: 10-90 % without condensation;
* Vlhkosť non-operation: 5-90 % without condensation
