QNAP QSW-M2106-4S 10/2,5 GbE Switch Managed 10-Port
QNAP QSW-M2106-4S 10/2,5 GbE Switch Managed 10-Port
Guarantee
24 month
Delivery from Europe in
10 - 15
business days
https://www. qnap .com/cs-cz/product/qsw-m2106-4s
Zoznam kompatibilty pre tento model: https://www. qnap .com/cs-cz/compatibility?model=734
B FunctionsB
The device QSW-M2106-4S is a web-controlled level 2 switch with four 10GbE SFP+ ports and six 2.5 Gigabit ports. The QSW-M2106-4S supports Layer 2 (L2) network management switching through a user-friendly web interface, offers flexible deployment in hybrid high-speed network environments, and provides an entry-level network management solution that can be used by non-IT professionals. Thanks to high performance, user-friendly management and table provision, the device QSW-M2106-4S allows a cost-effective upgrade to a 2.5 GbE or 10 GbE network with optimal bandwidth and secure network maintenance.
*Contains four 10GbE SFP+ ports (back-compatible with 1G SFP) for high-speed networks.
*Six 2.5 GbE RJ45 ports allow you to instantly increase the network speed by 2.5 times when using existing Cat 5e cables.
*Systém QNAP Switch System (QSS) is easy to use and has a clear control panel, port management and settings guide, thanks to which the central network management is intuitive.
*Provides level 2 management functions (such as LACP, VLAN, ACL and LLDP) for IT staff to effectively manage network bandwidth and increase security.
*Je jedim z mála webovo riadených prenčinciov that support Rapid Spanning Tree Protocol (RSTP). Enables simple and efficient deployment of small and medium networks, which support the expansion, redundancy and prevention of loops.
*QSS can be updated with a simple click, which helps IT workers to ensure network security.
B OBSAH BALENIAB
*QSW-M2106-4S
*Power cable
*Power adapter
*Quick Installation Guide (QIG)
SPECIFICATIONS
Message type
*Web report
Number of ports
*10
Combined ports 10GbE SFP+/RJ45
*4
2.5GbE (RJ45)
*6
B Description of the power supplyB
*Adapter
B Max. energy consumptionB
*16W
B Input power typeB
*DC
B Input voltage rangeB
*12V/3A
B MAC address tableB
*16K
B Total non-blocking gap B
*55 Gbps
B Switching capacityB
*110 Gbps
B Management interfaceB
*Web
B ConsoleB
*RJ45
B Energy-efficient Ethernet (pod IEEE 802.3az)B
*Yes
Fan
*Fan with double ball bearings PWM x 1
Supported standards
*IEEE 802.3 Ethernet
*IEEE 802.3u 100BASE-T
*IEEE 802.3ab 1000BASE-T
*IEEE 802.3z 1000BASE-SX/LX
*IEEE 802.3ae 10G Fiber
*IEEE 802.3x Full-Duplex Flow Control
*IEEE 802.1Q VLAN Tagging
*IEEE 802.1w RSTP
*IEEE 802.3ad LACP
*IEEE 802.1AB LLDP
*IEEE 802.3az Energy Efficient Ethernet
*IEEE 802.1p Class of Service
Shape factor
*Table
LED indicators
*Na porte: Rychłosť/Pripojenie/Činnosť
*Na device: Napájanie/Stav
Buttons
*Settings button
Dimensions (H x W x D)
*42.5 x 290 x 127 mm
Weight (net)
*1.15kg
Weight (total)
*1.75 kg
Operating temperature
*0 - 40 °C (32 °F - 104 °F)
Relative humidity
*Relative humidity 5 to 95%, non-condensing
B Rám JumboB
*9K
B More information can be found on the manufacturer page
| External accessories | |
|---|---|
| Number of LAN ports | 6 |
| Model design | |
| Fanless switch | No |
| Includes switch | Yes |
| Switch design | Desktop |
| Connection | |
| Number of SFP+ ports | 4 |
| Speed | |
| Maximum LAN speed | 10Gbps |
