GS2220-28 24xGbE L2 Switch GbE Uplink 1Y NCC Pro Pack License GS2220-28-EU0101F
Product reference:
3-4718937607440
GS2220-28 24xGbE L2 Switch GbE Uplink 1Y NCC Pro Pack License GS2220-28-EU0101F
GS2220-28 24xGbE L2 Switch GbE Uplink 1Y NCC Pro Pack License GS2220-28-EU0101F
Product reference:
3-4718937607440
GS2220-28 24xGbE L2 Switch GbE Uplink 1Y NCC Pro Pack License GS2220-28-EU0101F
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
9 - 14
business days
| Design | |
|---|---|
| Certification | LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A |
| Product colour | Black |
| Rack mounting | Yes |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240V |
| Power consumption (max) | 22.5W |
| Security | |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Security algorithms | SNMPv2, SSH-2, SSL/TLS, SNMP, SNMPv3 |
| IGMP snooping | Yes |
| Authentication | Guest VLAN, MAC-based authentication |
| Authentication type | IEEE 802.1x, RADIUS |
| DHCP features | DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay |
| Operational conditions | |
| Storage relative humidity (HH) | 10 - 95% |
| Storage temperature (TT) | -40 - 70 °C |
| Heat dissipation | 76,725 BTU/h |
| Operating relative humidity (HH) | 10 - 95% |
| Operating temperature (TT) | 0 - 50 °C |
| Management features | |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Configuring Location Settings (CLI) | Yes |
| Switch layer | L2 |
| System event log | Yes |
| Weight dimensions | |
| Width | 441 mm |
| Height | 44 mm |
| Depth | 131 mm |
| Weight | 2.2 kg |
| Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3az, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab 802.1D, IEEE 802.3z, IEEE 802.1s |
| Spanning tree protocol | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| 10G support | From |
| Flow control support | Yes |
| Rate limiting | Yes |
| Virtual LAN features | Private VLAN, Port-based VLAN, Protocol-based VLAN, Voice VLAN |
| VLAN support | Yes |
| Copper ethernet cabling technology | 10BASE-TX, 1000BASE-T |
| Performance | |
| Firmware upgradeable | Yes |
| Fanless | Yes |
| Internal memory | 256MB |
| Mean time between failures (MTBF) | 989157 hours |
| Flash memory | 32MB |
| Packaging data | |
| Package weight | 2.91 kg |
| Cables included | AC |
| Package depth | 214 mm |
| Package height | 79 mm |
| Package width | 558 mm |
| Ports interfaces | |
| Combo SFP port quantity | 4 |
| Basic switching RJ-45 Ethernet port type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet port quantity | 24 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Data transmission | |
| MAC address table | 16000 entries |
| Packet buffer memory | 1.5MB |
| Switching capacity | 56 Gbps |
| Forwarding rate | 42 Mpps |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | From |
| Multicast features | |
| Multicast support | Yes |
| Safety warning | |
| Warnings | Follow the safety guidelines for electrical current., Make sure the ventilation of the equipment is not blocked., Avoid contact of the device with liquid. |
