KEYBOARD WRL RAY68-HE / BROWN 103-RA68A-000 AKKO
Product reference: 2-6978414651801

KEYBOARD WRL RAY68-HE / BROWN 103-RA68A-000 AKKO

Product reference: 2-6978414651801
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
91,52 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Lightbox DIY fun

DIY Lightbox


The Ray68 HE Magnetic Keyboard isn't just a high-performance keyboard—it's also a platform for self-expression. With the built-in DIY Lightbox, you can personalize your keyboard's aesthetic like never before.



Full Range RT0.01mm

Achieve ultra-accurate 0.01mm Rapid Trigger and adjustable actuation distance in 0.01mm step. This allows users to fine-tune their typing or gaming experience, ensuring optimal actuation for faster response times with enhanced precision, ideal for competitive gaming.



Cross-Compatible with Mainstream Magnetic Switches

Ray68 HE Magnetic Keyboard provides compatibility with 5 third-party magnetic switches. Users can choose the appropriate switch from the Akko Driver list and calibrate the keyboard easily after replacement. Mixing and matching them in different keys is also possible.



Disclaimer: High-percision switches require tuning and experimenting with the keyboard. The switches listed are guaranteed to perform at 0.01mm precision. Other switches may work but are unable to reach the claimed accuracy. Mechanical switches are not supported.



ARM Cortex-M4 CPU

The powerful CPU delivers enhanced processing power with low energy consumption. It features automatic calibration between -20°C and 80°C, ensuring faster performance and extended battery life.



8,000Hz Polling Rate

Enjoy ultra-fast response times and smoother, more precise inputs—perfect for gaming and high-performance tasks.



Ray68 Wired Version supports an 8,000Hz polling rate for ultra-low latency and instant response.



For Ray68 Wireless Version (Tri-Mode), supports 8000Hz polling rate for all keys in wired or 2.4G wireless modes.



RT Stabilizer

This "RT Stabilizer" mode is especially useful when set to a Rapid Trigger precision of 0.005mm, as magnetic switch keyboards may experience unintended inputs or disconnection from slight hand tremors, which can disrupt the overall gaming experience.



ARGB at a 500Hz Refresh Rate

The Ray68 HE Magnetic Keyboard features ARGB(addressable RGB) with individually controlled LEDs for smooth, flicker-free lighting. With Alpha channel integration and a 500Hz refresh rate, it offers richer dynamic effects and reduces visual fatigue—perfect for gaming and aesthetic builds.



Snap Key

Snap Key, Akko's SOCD implementation, prioritizes the latest input for faster directional shifts, ensuring smooth, responsive control in FPS games.



Adjustable Actuation Distance

These magnetic switches allow users to adjust every key's actuation point from 0.1mm to 3.4mm, which offers different kinds of pressing for gaming or typing.



Rapid Trigger (RT)

Rapid Trigger eliminates actuation delay by instantly activating and deactivating keys with minimal travel—perfect for FPS gaming.



Dynamic Keystrokes (DKS)

A single key supports four actions—light press for action 1, deeper press for action 2, and two-stage release settings.



Toggle Key (TGL)

TGL (Toggle Key) turns a key into a switch that can either hold a function or trigger it repeatedly at high speed.



Mod-Tap

Mod Tap allows dual-function keys—tap for one action, hold for another—offering greater gaming convenience.



Built-in 8000mAh Battery

With a high-capacity battery of around 8000mAh, users can enjoy prolonged periods of uninterrupted typing, gaming, or productivity without the need for constant recharging.



Multi-Mode

Ray68 HE Magnetic Keyboard can be connected to multiple devices through Bluetooth 5.0, multi-host 2.4Ghz (with a receiver), and wired Type-C modes with an easy switch.



Web & Cloud Driver

Full Customization for Lighting, Keys, and Macros.



PC+ABS Keycaps

Durable & Balanced


Made from a blend of PC and ABS, these keycaps combine the toughness of polycarbonate with the smooth feel of ABS, ensuring long-lasting use with a refined typing experience.


Apšvietimo spalva RGB
Baterijos svoris 180 g
Baterijos talpa 8000 mAh
Battery weight 180 g
Bluetooth versija 5.0
Bruto svoris 1.3 kg
Dažnių juosta 2.4 GHz
Diskretizavimo dažnis 8000 Hz
Fizinis išdėstymas ANSI
Foninio apšvietimo tipas RGB LED
Foninis apšvietimas Taip
Instrukcija Taip
Kelių įrenginių palaikymas Taip
Kintamosios srovės adapteris Ne
Klaviatūros baterijos tipas Integruota baterija
Klaviatūros forma 65%
Klaviatūros išdėstymas QWERTY
Klaviatūros kalba Anglų (JAV)
Klaviatūros klavišų perjungimo technologija Akko AstroAim Magnetic
Klaviatūros klavišų skaičius 68
Klaviatūros matmenys (WxDxH) 119 x 317 x 38 mm
Klaviatūros pagrindinis jungiklis Magnetinis klavišų jungiklis
Klaviatūros stilius Tiesus
Klavišų galvučių medžiaga ABS/PC
Klavišų išėmimo įrankis Taip
Maitinimo šaltinio tipas Battery,USB
Medžiaga Akrilonitrilo butadieno stirenas (ABS)
Neto svoris 1.22 kg
Pakeitimas neišjungus Taip
Paviršiaus nudažymas Monochromatinis
Pelė įskaityta Ne
Pridėtas imtuvas Taip
Produkto spalva Juoda
Produktų skaičius pakuotėje 1 vnt
Reguliuojamas apšvietimas Taip
Rekomenduojamas naudojimas Žaidimams
Rodomasis įtaisas Ne
Ryšio technologija Vielinis ir Bevielis
Shipping Box Depth 47.5 cm
Shipping Box Height 37.5 cm
Shipping Box Weight 18.25 kg
Shipping Box Width 38 cm
Skaitinė klaviatūra Ne
Summary Akko Ray68 HE. Keyboard form factor: 65%. Keyboard style: Straight. Connectivity technology: Wired & Wireless, Device interface: USB + RF Wireless + Bluetooth, Keyboard key switch: Magnetic key switch, Keyboard layout: QWERTY, Keyboard number of keys: 68. Backlight type: RGB LED. Recommended usage: Gaming. Product colour: Black
Svoris 1220 g
Unit Box Height 0.175
Unit Box Length 0.37
Unit Box Width 0.065
Unit Brutto Volume 0.004835 cubm
USB jungtis C tipo USB
USB "Type-C" įkrovimo lizdas Taip
Vendor Homepage https://akkogear.eu/products/ray68-he-magnetic-keyboard?variant=45362118852807
Vieneto aukštis 17.5 cm
Vieneto gylis 37 cm
Vieneto plotis 6.5 cm
Vienetų skaičius vienoje siuntimo dėžėje 14
Windows klavišai Taip
Įkraunama Taip
Įrenginio sąsaja USB + RF Wireless + Bluetooth
