Epson ELPDC07 document camera

Epson ELPDC07. Effective sensor resolution: 2 MP, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Sensor type: CMOS. Optical zoom: 8x, Digital zoom: 8x, Shooting area (WxD): 297 x 420 mm. Interface: USB 2.0, USB connector type: USB Type-B. Power supply type: USB, Power consumption (typical): 2.5 W, Power consumption (standby): 2.5 W. Width: 260 mm, Depth: 60 mm, Height: 76 mm

Portable visualiser
Let a wide audience get up close to your source material with the Epson ELPDC07 visualiser. Delivering high-quality images, this portable and adaptable camera sets up quickly and can be connected directly to the latest Epson projectors.

See in great detail
Share high-quality visuals including detailed diagrams and textbook pages with a Full HD 1080p output and 8x digital zoom. You can even adjust the height and rotate the camera 90º to accommodate 3D objects.

Effortless to use
Minimise preparation time with this high-tech, compact and affordable portable solution, that makes it quick and easy to enlarge source material. In just seconds, you can connect directly to the latest Epson projectors using the two in one USB cable connection which provides power and transmits the video signal.

Highly portable, modern design
The Epson ELPDC07 visualiser is neat and compact, it features LED illumination, a built-in microphone and doesn't need a separate power supply. It's also light and easy to carry in the included carry case, with the arm folding neatly down into the base. Needing just 2.5W, you can be sure that its power consumption meets modern energy conservation requirements .

Camera

Effective sensor resolution: 2 MP
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Sensor type: CMOS
Supported graphics resolutions: 1920 x 1080 (HD 1080)
Maximum frame rate: 30 fps
Feature: Image freeze
Light source: LED

Lens system

Feature: Auto focus
Optical zoom: 8x
Digital zoom: 8x
Shooting area (WxD): 297 x 420 mm

Ports & interfaces

Interface: USB 2.0
USB connector type: USB Type-B

Technical details

Product colour: White
Display modes: Microscope
Feature: Cable lock slot
Cable lock slot type: Kensington
Box contents: Carrying Case, Information sheet, USB cable, Warranty document
Bundled software: Easy Interactive Tools, TWAIN driver for Epson Document Camera (for Windows)
Feature: Illumination
Image quality adjustment: Brightness
Security features: Kensington lock
Special features: Auto focus, Freeze
Feature: Zoom capability
Country of origin: Philippines

Power

Power supply type: USB
Power consumption (typical): 2.5 W
Power consumption (standby): 2.5 W

Weight & dimensions

Width: 260 mm
Depth: 60 mm
Height: 76 mm
Weight: 1 kg
Dimensions folded (WxDxH): 260 x 60 x 76 mm

Packaging data

Quantity per pack: 1 pc(s)
Package width: 195 mm
Package depth: 320 mm
Package height: 120 mm
Package weight: 1.73 kg

Packaging content

Feature: Carrying case
Cables included: USB
Feature: Warranty card
