Lindy 42794 interface hub

Lindy 7 Port USB 2.0 Metal Hub. Host interface: USB 2.0 Type-B, Hub interfaces: USB 2.0. Data transfer rate: 480 Mbit/s, Product colour: Black, Housing material: Metal. Power supply type: DC, Output voltage: 5 V, Output current: 3.2 A. Width: 165 mm, Depth: 48 mm, Height: 24 mm. Quantity per pack: 1 pc(s), Package width: 222 mm, Package depth: 156 mm

The Lindy 7 Port USB 2.0 Metal Hub has been designed to provide reliable performance in demanding operating environments.

This industrial-grade hub features a rugged, all-metal chassis providing excellent EMC protection. With robust metal housing and integrated mounting brackets this Hub is the ideal solution for industrial environments.

Each USB port port features individual short circuit protection. The included power supply ensures secure and uninterrupted electricity supplies.

Ports & interfaces

Host interface: USB 2.0 Type-B
Hub interfaces: USB 2.0
USB 2.0 ports quantity: 7
Ports quantity: 7
Feature: DC-in jack

Features

Data transfer rate: 480 Mbit/s
Product colour: Black
Housing material: Metal
LED indicators: Yes
Cable length: 1.8 m
Certification: CE, UKCA, FCC, RoHS, REACH, California Proposition 65

Power

Power supply type: DC
Output voltage: 5 V
Output current: 3.2 A
Power note: 5.5/2.1mm DC

Weight & dimensions

Width: 165 mm
Depth: 48 mm
Height: 24 mm
Weight: 251 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 222 mm
Package depth: 156 mm
Package height: 40 mm
Package weight: 648 g
Package type: Box

Packaging content

Included power plug types: AU, EU, UK, US
Cables included: USB Type-A to USB Type-B

Operational conditions

Minimum operating temperature: 0 °C
Maximum operating temperature: 50 °C
Operating temperature (T-T): 0 - 50 °C
Operating temperature (T-T): 32 - 122 °F
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 90%

Logistics data

Harmonized System (HS) code: 84719000

Other features

Chipset: FE 2.1
