Lenovo 40B00300EU laptop dock / port replicator

Lenovo 40B00300EU. Connectivity technology: Wired, Host interface: Thunderbolt 4, USB Power Delivery up to: 230 W. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, Red, Data transfer rate: 40 Gbit/s, HD type: 8K Ultra HD. Power supply: 300 W, Output voltage: 20 V, Output current: 15 A. Windows operating systems supported: Windows 10

Premium Thunderbolt™ 4 Docking Experience: ThinkPad Thunderbolt 4 Workstation Dock delivers reliable and consistent industry leading video, data and power connectivity; Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, Upto 230W Power Delivery to Workstation, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps.; The ThinkPad Thunderbolt 4 Workstation Dock is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.

Ports & interfaces

Connectivity technology: Wired
Host interface: Thunderbolt 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
Feature: USB Power Delivery (USB PD)
USB Power Delivery up to: 230 W
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 2
DisplayPort version: 1.4
Thunderbolt 4 ports quantity: 1
Feature: Combo headphone/mic port
Feature: DC-in jack

Network

Feature: Ethernet LAN
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 10,100,1000 Mbit/s

Performance

Data transfer rate: 40 Gbit/s
HD type: 8K Ultra HD
Maximum digital resolution: 7680 x 4320 pixels
Number of displays supported: 4
Maximum refresh rate: 30 Hz
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: VESA mounting
Product colour: Black, Red
LED indicators: Yes
Certification: cULus, FCC, ICES, NOM

Power

Power supply: 300 W
Output voltage: 20 V
Output current: 15 A
Power consumption (max): 230 W

Software

Windows operating systems supported: Windows 10

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 220 mm
Depth: 80 mm
Height: 30 mm
Weight: 450 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 270 mm
Package depth: 195 mm
Package height: 85 mm
Package weight: 1.9 kg

Packaging content

Feature: Warranty card
Cables included: AC
Feature: AC adapter included

Logistics data

Harmonized System (HS) code: 84733020
