Next-generation, wide voltage range 4G LTE Cat 1 vehicle tracking device, mounted on a car battery and featuring higher GNSS accuracy
Ways to use the tracker:
• By inserting a SIM card with a minimum Internet plan (e.g. Teledema, Tele2 telemetry ~2.5 EUR/month), when you call the device, you will receive an SMS response with a position link on Google maps.
• By sending the appropriate SMS command to the tracker, you can receive responses with various technical parameters, such as position coordinates, battery level, information update frequency, etc.
• Using the online platform trackmap.lt (registration is paid, see attachments below) you can monitor the movement of an object on your computer / phone in real time, see historical data. Monitor groups of vehicles or personnel. (You can see what it looks like by logging in and entering the username and password "demo", without quotes). Short instructions.
Product
Model number FTC921-QJAB0
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU
Receive type 135 tracking/acquisition channels
Tracking sensitivity -165 dBM
Position Accuracy < 1.8 m CEP
Velocity Accuracy < 0.1 m/s (within +/- 15% error)
Communication technology
2G bands GSM: B2/B3/B5/B8
4G LTE will test LTE FDD (CAT 1): B1/B3/B5/B7/B8/B20/B28
4G LTE will test LTE FDD (CAT 1): B1/B3/B5/B7/B8/B20/B28
Data transfer
LTE FDD (CAT 1): Max. 10 Mbps (DL) / Max. 5 Mbps (UL)
GSM (GPRS): Max. 85.6 Kbps (DL) / Max. 85.6 Kbps (UL)
Transmit power
Class 5 for GSM850/900: 30±5dBM
Class 3 for GSM1800/1900: 29±5dBM
Class 3 for LTE-FDD: 26±5dBM
Data support SMS (TEXT, PDU), Network protocols (TCP)
Data codec
Codec support Codec 8 Extended
Power supply
Input voltage range 10–90 V
Internal Back-up battery 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse 3A, 125V
Internal Back-up battery 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse 3A, 125V
Power consumption
At 12V < 25 mA (nominal with no load)
At 12V < 0.25A Max (with full Load/Peak)
Physical characteristics
Dimensions 93 x 43 x 12.5 mm (L x W x H)
Weight 65 g
Weight 65 g
Operating environment
Operating temperature (without battery) -40 °C to +85 °C
Storage temperature (without battery) -40 °C to +85 °C
Operating temperature (with battery) 0 °C to +40 °C
Storage temperature (with battery) -20 °C to +60 °C
Operating humidity 65 ± 20% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage conditions 65 ± 20%RH
Storage temperature (without battery) -40 °C to +85 °C
Operating temperature (with battery) 0 °C to +40 °C
Storage temperature (with battery) -20 °C to +60 °C
Operating humidity 65 ± 20% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage conditions 65 ± 20%RH
-10 °C to +50 °C for 1 month
-10 °C to +35 °C for 3 months
0 °C to +30 °C for 1 year
Interfaces
Digital Inputs 1
Digital Outputs 1
Analog Inputs 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB USB 2.0 USB Type-C
LED indication 2 status LED lights
SIM Nano-SIM
Memory 128MB internal flash memory
Digital Outputs 1
Analog Inputs 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB USB 2.0 USB Type-C
LED indication 2 status LED lights
SIM Nano-SIM
Memory 128MB internal flash memory
Features
Sensors Accelerometer
Scenarios Green Driving, Over Speeding detection, Jamming detection, Excessive idling detection, Unplug detection, Crash Detection, Trip
Sleep modes Deep Sleep
Configuration and firmware update FOTA WEB, Teltonika Configuration Tool (TCT)
SMS Configuration, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization GNSS, NITZ, NTP
Ignition detection Digital Input 1, Accelerometer, External Power Voltage
Scenarios Green Driving, Over Speeding detection, Jamming detection, Excessive idling detection, Unplug detection, Crash Detection, Trip
Sleep modes Deep Sleep
Configuration and firmware update FOTA WEB, Teltonika Configuration Tool (TCT)
SMS Configuration, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization GNSS, NITZ, NTP
Ignition detection Digital Input 1, Accelerometer, External Power Voltage
Certificates
Regulatory FTC921-QJAB0: CE/RED, E-Mark, RCM (Planned, not started.), RoHS, REACH, Pulse 5b
User manual - https://wiki.teltonika-gps.com/view/FTC921 (you can change the language in the upper right corner).
User manual
Link to product description on manufacturer's website
