The 1 inch DC electronic irrigation valve operates at 9-24 V DC and features pulse control for efficient water flow control. It is designed for automatic irrigation systems operating in the pressure range of 0.2-10 bar and has an IP68 rating for moisture resistance.
The 1 inch DC electronic irrigation valve operates at 9-24 V DC and features pulse control for efficient water flow control. It is designed for automatic irrigation systems operating in the pressure range of 0.2-10 bar and has an IP68 rating for moisture resistance.


The 1 inch DC electronic irrigation valve operates at 9-24 V DC and features pulse control for efficient water flow control. It is designed for automatic irrigation systems operating in the pressure range of 0.2-10 bar and has an IP68 rating for moisture resistance.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
The 1" DC Electronic Irrigation Valve operates at 9-24 V DC and has pulse control for efficient water flow control. It is designed for automatic irrigation systems with a pressure range of 0.2-10 bar and has an IP68 rating for moisture resistance.
Features | |
|---|---|
| Product Type | Irrigation Valve |
| Product Brand | RainPoint |
| Model | BIV025ESC-DC |
Specifications | |
| Connector Diameter | 1" BSP |
| Operating Voltage | 9-24 V DC (Latch) |
| Control Type | Pulse (DC Latch) |
| Pulse Duration | ≥200ms |
| Minimum Capacitance | 4700 µF |
| Operating Pressure | 0.2-10 bar |
| Operating Temperature | up to 60°C |
| Protection Class | IP68 |
Additional Information | |
| Features |
|
| Safety Warning | Use the product only for its intended purpose in irrigation systems. |
| Height | 120mm |
| Length | 180mm |
| Weight | 650g |
| Width | 120mm |
