Flash Yongnuo YN685EX-RF for Sony

Flash Yongnuo YN685EX-RF for Sony

Yongnuo YN685EX-RF is a professional flash with a high-power and efficient power supply. This model is designed for Sony cameras (Multi Interface hot shoe). The device is equipped with a receiver and transmitter that allows you to communicate with the Yongnuo radio trigger system. It can operate both as a "slave" and as a "master" device. The flash can operate in manual, flash and TTL modes. It also offers HSS high-speed synchronization (up to 1/8000 s) and optical flash triggering (Sc, S1, S2). It also allows you to control 5 flash groups in 16 channels. Powered by 4 AA batteries, you will be able to take from 100 to 1500 shots, depending on the selected power level.

Specification

•


  model: Yongnuo YN685EX-RF, for Sony





•


  number of guides: GN 60 (ISO 100, 200 mm)





•


  flash power adjustment: 1/128 - 1/1 with 1/3 EV steps





•


  flash modes: manual M, flash Multi, auto TTL, Gr





•


  launch methods:





  •


    light on the camera





  •


    RX and TX radio mode





  •


    photocell Ss, S1, S2









•


  torch zoom: 20, 24, 28, 35, 50, 70, 105, 135, 200 mm





•


  vertical torch movement range: -7° ~ 90°





•


  horizontal torch movement range: 180° in each direction





•


  Power supply: 4 x AA batteries (alkaline or Ni-MH)





•


  Battery life: 100-1500 flashes (for AA alkaline batteries)





•


  torch charging time: approx. 2 s





•


  flash color temperature: 5600 K





•


  flash time: 1/200 - 1/20000 s





•


  High-speed sync (HSS): up to 1/8000 s





•


  Flash power control: 8 power control levels (1/128 ~ 1/1), 22 adjustment levels





•


  external connections:





  •


    Multi Interface hot shoe (for Sony)





  •


    PC port





  •


    Computer port





  •


    Computer port





  •


    External power outlet





  •


    Micro USB port





  •


    micro USB port









•


  Radio trigger range: up to 100 meters





•


  Photocell range: up to 100 meters





•


  photocell range:





  •


    20-25 m indoors





  •


    10-14 m outdoors









•


  Weight: 427 g





•


  Weight: 427 g




Compatibility

•


  Sony cameras with multi-interface flash sockets





•


  Sony cameras with multi-interface flash sockets





•


  "Sony" cameras with a computer socket (using a computer sync cable)





•


  Radio flash control system





•


  Yongnuo RF603 and RF602 radio flash control system





•


  receive and respond to signals from: YN650EX-RF, YN685EX-RF, YN320EX, YN685(II), YN720, YN560 IV, YN660, YN650 III and controllers and triggers: YN650-TX (pro), YN32-TX





•


  Compatible with most flashes on the market in S1 and S2 modes




Kit contents

•


  Yongnuo YN685EX-RF flash for Sony





•


  flash bag





•


  base
