VIDEO SWITCH KVM DP / HDMI / CSV-7210 CLUB3D
Product reference:
3-8719214472238
VIDEO SWITCH KVM DP/HDMI/CSV-7210 CLUB3D
VIDEO SWITCH KVM DP / HDMI / CSV-7210 CLUB3D
Product reference:
3-8719214472238
VIDEO SWITCH KVM DP/HDMI/CSV-7210 CLUB3D
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 16
business days
The CSV-7210 is a high performance DisplayPort™ KVM (Keyboard Video and Mouse) switcher. It routes high definition videos up to 4096x2160 at 60Hz resolution and audio from any DisplayPort™ source to any HDMI™ or DisplayPort™ supported display. This DisplayPort™ KVM switcher not only has the key press switching function, but also has an intelligent function as well as hot pluggable function.
- Support resolution up to 4Kx2K@60Hz
- Support RGB 4:4:4/ YCbCr 4:4:4/ YCbCr 4:2:2/ YCbCr 4:2:0
- Support KVM function
- Support a DisplayPort™ or HDMI™ display and a set of Keyboard and Mouse to control two PCs with DisplayPort™ ports
| Summary: | CLUB3D DisplayPort/HDMI KVM Switch For Dual DisplayPort 4K 60Hz. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI/DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 4096 x 2160 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal. Power source: DC, Input voltage: 5 V, Power consumption (typical): 12 W. Width: 178 mm, Depth: 75 mm, Height: 26 mm |
| Vendor Homepage: | https://www.club-3d.com/en/detail/2595/displayport-hdmi_kvm_switch_for_dual_displayport_4k_60hz/ |
| Category Code: | SWK |
| CnCode: | 85176200 |
| Unit Box Height: | 0.18 |
| Unit Box Length: | 0.23 |
| Unit Box Width: | 0.055 |
| Audio connections: | Yes |
| Console port: | 3.5mm headphone/3.5mm mic/HDMI/USB B |
| DC-in jack: | Yes |
| DisplayPort quantity: | 3 |
| HDMI ports quantity: | 1 |
| Headphone outputs: | 4 |
| Keyboard port type: | USB |
| Mouse port type: | USB |
| Number of computers controlled: | 2 |
| Number of microphone inputs: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B port quantity: | 2 |
| Video port type: | HDMI/DisplayPort |
| Data transfer rate (max): | 32.4Gbit/s |
| HD type: | 4K Ultra HD |
| HDCP: | Yes |
| HDCP version: | 1.4/2.2 |
| High Dynamic Range (HDR) supported: | Yes |
| Maximum resolution: | 4096 x 2160pixels |
| Plug and Play: | Yes |
| Video bandwidth: | 60Hz |
| Housing material: | Metal |
| LED indicators: | Yes |
| Product colour: | Black |
| Rack mounting: | From |
| Built-in display: | From |
| External power adapter: | Yes |
| Input voltage: | 5V |
| Power consumption (typical): | 12W |
| Power source: | DC |
| Linux operating systems supported: | Yes |
| Mac operating systems supported: | Yes |
| Windows operating systems supported: | Yes |
| Operating relative humidity (HH): | 10 - 85% |
| Operating temperature (TT): | 0 - 45°C |
| Storage relative humidity (HH): | 5 - 90% |
| Storage temperature (TT): | -10 - 80°C |
| Depth: | 75mm |
| Height: | 26mm |
| Weight: | 370g |
| Width: | 178mm |
| Package depth: | 65mm |
| Package height: | 210mm |
| Package type: | Box |
| Package weight: | 787g |
| Package width: | 230mm |
| Paper/cardboard packaging weight: | 147g |
| Plastic packaging weight: | 6g |
| Total paper/cardboard packaging weight: | 0g |
| Total plastic packaging weight: | 0g |
| AC adapter included: | Yes |
| Cables included: | USB Type-A to USB Type-B |
| Quick installation guide: | Yes |
| Remote control included: | Yes |
| Harmonized System (HS) code: | 8473 3020 |
| Model: | CSV-7210 |
| Model name: | DisplayPort/HDMI KVM Switch For Dual DisplayPort 4K 60Hz |
| Units per Pallet: | 0 |
| Unit Calculated Volume: | 0.002277m³ |
| Unit Calculated Weight: | 0.79kg |
