Electric vehicle charging station Reach CS04-11 Type2 16A 11kW 5.0m

Specification:
Connector type: Type 2
Charging current: up to 16 A
Maximum charging power: 11 kW
Cable length: 5 m
Protection class: IP65
Operating voltage: AC 380-480 V
Block size: 250 × 270 × 90 mm
Operating temperature: -30 °C ~ +50 °C
Warranty: 24 months.

Protection against electric leakage, overcurrent, earth fault, overvoltage and undervoltage, overfrequency and underfrequency and overheating. Protection against electric leakage: Type B RCD (30 mA AC + 6 mA DC).

The set includes: charging station with Type 2 charging cable, wall bracket for the station, 5 pcs. M3.5 × 35 mm mounting screws with dowels, 2 pcs. M3 × 10 mm screws for the wall bracket.

Charging control
The charging station has integrated control buttons that can be used to change the charging current and set a delayed start of charging.

Real-time charging monitoring
The integrated digital display provides information about the charging process in real time, so the main charging parameters can be conveniently monitored on the station's screen.

The following parameters are displayed:
Charging current: current charging current.
Charging time: How long it takes to charge.
Mains voltage: current mains voltage.
Charging power: current charging power.
Delayed charging time: Set the time until charging starts.
Accumulated energy: The amount of energy transferred during charging.
Signal voltage: displayed on the station display.

LED status indicator
The station has an integrated LED indicator that uses different colors to indicate the device and charging status. Green, blue, and red are used to indicate operating, charging, and possible fault states.
