Electric vehicle charger Reach PEVC1 220V GBT 16A 3.5kW 5.0m

Specification:

Connector type: GBT and Schuko plug
Charging current: 6-16 A (1 phase, adjustable)
Maximum charging power: 3.5 kW
Cable length: 5 m
Protection class: IP65
Operating voltage: AC 200-250 V
Block size: 210 × 86 × 50 mm
Operating temperature: -30 °C ~ +50 °C
Operating humidity: 5% ~ 95% RH
Protections: against electrical leakage, overvoltage, undervoltage, overcurrent and overheating
Warranty: 24 months.

The set includes: charging station, power cord, wall mount with mounting screws, cleaning cloth.

Real-time charging management
| The integrated LED display provides detailed information about the charging process in real time, allowing you to conveniently monitor and control key charging parameters.

The following parameters are displayed:
Maximum current: The selected maximum current that the charger can use.
Accumulated energy: Total energy transferred during the charging session.
Charging time: How long it takes to charge.
Charging unit temperature: current temperature of the control unit.
Mains voltage: current mains voltage.
Instantaneous charging power: the actual power supplied to the car at this moment.
Instantaneous charging current: current charging current.

On-screen control menu options:
Current change: charging current can be selected - 6 A / 8 A / 10 A / 13 A / 16 A.
Setting the charging start time: You can set a delay for the charging start until 12 hours, changing it at 1 hour intervals.
Grounding mode control: charging mode can be selected with or without grounding, depending on the conditions of use.
Stopping charging: The charging process can be stopped using the buttons on the control unit.

Control via mobile app, and when there is no network, via Bluetooth
Reach PEVC1 has an integrated smart control system that allows you to control the charger via a mobile app. During the first connection, the phone and charger are paired using Wi-Fi and Bluetooth connection. If there is no Wi-Fi network, you can use your phone's mobile hotspot for the first pairing. After the first successful connection, the device can also be controlled via Bluetooth.

The app allows you to:

• Start and stop charging


• Select charging mode


• Set charging start time


• Adjust charging current


• View charging history


• Change grounding and other system settings


• Share device control with another app user
