USB C Docking Station - LINDY Plugable DST-Mini XT 810 8K / 4K60, 100W PD, USB 3.2, Gigabit Ethernet, Gray
Product reference:
14-4002888433921
The DST-Mini XT 810 is a USB-C laptop mini dock that supports single-display output up to 8K or dual-display output at 4K60. It features 100W pass-through charging, multiple USB ports, Gigabit Ethernet, and audio jacks.
USB C Docking Station - LINDY Plugable DST-Mini XT 810 8K / 4K60, 100W PD, USB 3.2, Gigabit Ethernet, Gray
Product reference:
14-4002888433921
The DST-Mini XT 810 is a USB-C laptop mini dock that supports single-display output up to 8K or dual-display output at 4K60. It features 100W pass-through charging, multiple USB ports, Gigabit Ethernet, and audio jacks.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Plugable DST-Mini XT 810 8K/4K60, 100W PD, USB 3.2, Gigabit Ethernet, Gray
The DST-Mini XT 810 is a USB-C laptop mini dock that supports single-display output up to 8K or dual-display output 4K60. It features 100W pass-through charging, multiple USB ports, Gigabit Ethernet, and audio jack.
- Supports single-screen output for up to 8K (7680x4320) 30Hz or dual-screen output for 4K (3840x2160) 60Hz each.
- Equipped with 100W Power Delivery for fast charging and a variety of connectivity options, including HDMI®, DisplayPort, USB Type A/C, and Gigabit Ethernet.
- Compact and lightweight design with aluminum body, perfect for travel.
- Compatible with USB Type C/Thunderbolt devices running on a variety of operating systems, including Windows, macOS, and Linux.
Features | |
|---|---|
| Product type | USB-C dock |
| Model | DST-Mini XT 810 |
Specifications | |
| Connection | USB Type C to 1x HDMI®, 1x DisplayPort, 2x USB Type A, 2x USB Type C, 1x RJ45, 1x SD, 1x microSD, 1x 3.5mm audio (combined) |
| Supported bandwidth | HDMI® 2.1 (48Gbps), DP 1.4a (32.4Gbps), USB 3.2 / 3.1 (up to 10 Gbps), Gigabit LAN (10/100/1000 Mbps) |
| Maximum input resolution | 8K (7680x4320) 30Hz |
| Maximum output resolution | One screen: 7680x4320 30Hz, 3840x2160 120Hz; Two screens: 3840x2160 60Hz each |
| Chipset | VMM6210, VL822, GL3510, GL3224, RTL8153B, ALC4032, VL102 |
| Compatibility | USB Type C/Thunderbolt devices with DisplayPort Alternate Mode support (Windows, macOS, Linux, Android, ChromeOS) |
| Power Delivery | PD 3.0 to 100W (20V 5A) |
| HDCP support | HDCP 1.4 2.2 |
| Supported audio | Sample frequency 192kHz/24bit |
| Special features | DisplayPort Alternate Mode, MST extended display support, Battery Charging 1.2, simultaneous card reading, PXE, Wake on LAN, MAC address transfer |
Physical properties | |
| Dimensions | 270 x 45 x 16 mm |
| Cable length | 360mm |
| Housing material | Aluminum |
| Net weight | 0.23 kg |
| Working temperature | 0°C - 40°C |
| Safety temperature | -10°C - 70°C |
| Humidity | 0% - 85% RH (non-condensing) |
| Power | 15W |
| Color | Anthracite |
Safety warning | |
| Use the product only for its intended purpose to avoid hazards. | |
www.lindy.lt
| Height | 35mm |
| Length | 365 mm |
| Weight | 330 g |
| Width | 93 mm |
