The 7.5m DisplayPort 1.2 cable with male connectors supports a maximum resolution of 4096x2160 at 60Hz and a bandwidth of 21.6 Gbps. The cable has gold-plated connectors, a PVC jacket and operates in a temperature range of -10°C to 80°C.
The 7.5m DisplayPort 1.2 cable with male connectors supports a maximum resolution of 4096x2160 at 60Hz and a bandwidth of 21.6 Gbps. The cable has gold-plated connectors, a PVC jacket and operates in a temperature range of -10°C to 80°C.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
7.5 m DisplayPort 1.2 cable with male connectors supports a maximum resolution of 4096x2160 at 60Hz and a bandwidth of 21.6Gbps. The cable has gold-plated connectors, a PVC jacket and operates in a temperature range of -10°C to 80°C.
Features | |
|---|---|
| Product type | DisplayPort cable |
| Model | 7.5m DisplayPort 1.2 cable, Anthra Line DP Male to Male |
Specifications | |
| Connectors | DP Male to DP Male |
| Housing | ABS |
| Pin construction | Copper |
| Dimensions (approximate) | 20.4 x 36.0 x 12.7 mm |
| Cable length | 7.5m |
| Standard | DP 1.2 |
| Shell material | PVC |
| Cable material | Galvanized copper |
| Wire thickness | 26AWG |
| Armor | Aluminum magnesium braid 50% |
| Supported bandwidth | 21.6Gbps |
| Maximum resolution | 4096 x 2160 @ 60Hz 4:4:4 10bit |
| Nominal attenuation | 100MHz - 450MHz > -2.44dB, 450MHz - 8100MHz > -5.094dB |
| Minimum bending radius | 85mm |
| Operating temperature | -10°C to 80°C |
| Safety temperature | -25°C to 85°C |
Safety warning | |
| Use the product for its intended purpose to ensure safety and optimal performance. | |
