DeepCool PF600X power supply unit

Product reference: 6-R-PF600X-HD0B-JGEU

DeepCool PF600X power supply unit

Product reference: 6-R-PF600X-HD0B-JGEU

DeepCool PF600X power supply unit

You have 3 products in compare list, please remove someone and try again

Add to compare

5244 €

Product in warehouse

Guarantee
36 month

Delivery from Europe in
6 - 11
business days

Sustainability certificates	China RoHS WEEE Triman
Sustainability compliance	Yes
Fan diameter	12 cm
Number of fans	1 fan(s)
Product colour	Black
Cooling type	Active
Max output current (-12V)	0.3 A
Combined power (-12V)	3.6 W
Total power	600 W
Power protection features	OTP UVP OPP SCP NLO OVP OCP SIP
Efficiency	88%
Combined power (+3.3V)	100 W
Power Factor Correction (PFC) type	Active
Combined power (+5Vsb)	15 W
Max output current (+5Vsb)	3 A
Max output current (+5V)	16 A
Max output current (+3.3V)	16 A
Combined power (+12V)	600 W
Power Good signal delay range	100 - 150 ms
Combined power (+5V)	100 W
Hold time	16 ms
Max output current (+12V)	50 A
AC input frequency	50/60 Hz
Input current	5 A
AC input voltage	200 - 240 V
Operating temperature (T-T)	0 - 40 °C
Depth	140 mm
Height	86 mm
Width	150 mm
Bearing technology	HYB
Mean time between failures (MTBF)	40000 h
80 PLUS certification	80 PLUS Bronze
ATX version	2.52
Power supply unit (PSU) form factor	ATX
Purpose	PC
Cables included	AC
Compliance certificates	KC CCC RCM CE
Motherboard power connector	24-pin ATX
PCI Express power connectors (6+2 pin)	2
Motherboard power cable length	55 cm
SATA power cable length	600 450 mm 900 mm 750 mm
CPU power connector (4+4 pin)	Yes
Number of SATA power connectors	8
