Intel Xeon 6349P processor

Intel Xeon 6349P. Processor family: Intel® Xeon®, Processor socket: LGA 1700, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, PCI Express configurations: 2x8+1x4, 1x16+1x4. Microprocessor PCIe Revision: Gen 5. Maximum internal memory: 128 GB

Processor

Processor manufacturer: Intel
Processor model: 6349P
Processor base frequency: 3.6 GHz
Processor family: Intel® Xeon®
Processor cores: 6
Processor socket: LGA 1700
Processor threads: 12
System bus rate: 16 GT/s
Processor operating modes: 64-bit
Performance cores: 6
Processor boost frequency: 5.7 GHz
Processor cache: 18 MB
Thermal Design Power (TDP): 95 W
Package type: Tray
Maximum number of DMI lanes: 8
Processor codename: Raptor Lake
Processor ARK ID: 241611

Memory

Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 4800 MHz
Memory channels: Dual-channel
ECC: Yes

Graphics

On-board graphics card: No
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available

Features

Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Market segment: Server
Use conditions: Server/Enterprise
Maximum number of PCI Express lanes: 20
PCI Express slots version: 5.0
PCI Express configurations: 2x8+1x4, 1x16+1x4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Embedded options available: No

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel Trusted Execution Technology: Yes
Intel® Transactional Synchronization Extensions: No
Intel® Total Memory Encryption: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Turbo Boost Max Technology 3.0: Yes
Intel® Boot Guard: Yes
Mode-based Execute Control (MBE): Yes
Intel® Optane™ DC Persistent Memory Supported: No
Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
Microprocessor PCIe Revision: Gen 5
Intel® Total Memory Encryption - Multi Key: Yes

Operational conditions

Tjunction: 100 °C

Technical details

Launch date: Q1'25
Status: Launched
Memory speed (max): 4800 MHz
Servicing status: Baseline Servicing

Other features

Maximum internal memory: 128 GB
