Intel Xeon E-2414 processor

Intel Xeon E-2414. Processor family: Intel Xeon E, Processor socket: LGA 1700, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, PCI Express configurations: 2x8+1x4, 1x16+1x4. Intel® Turbo Boost Technology 2.0 frequency: 4.5 GHz, Microprocessor PCIe Revision: Gen 5. Maximum internal memory: 128 GB

Processor

Processor manufacturer: Intel
Processor model: E-2414
Processor base frequency: 2.6 GHz
Processor family: Intel Xeon E
Processor cores: 4
Processor socket: LGA 1700
Processor threads: 4
System bus rate: 16 GT/s
Processor operating modes: 64-bit
Performance cores: 4
Processor boost frequency: 4.5 GHz
Processor cache: 12 MB
Thermal Design Power (TDP): 55 W
Package type: Tray
Stepping: B0
Maximum number of DMI lanes: 8
Processor codename: Raptor Lake
Processor ARK ID: 236193

Memory

Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR5-SDRAM
Memory channels: Dual-channel
Feature: ECC

Graphics

On-board graphics card model: Not available
Discrete graphics card model: Not available

Features

Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Server
Use conditions: Server/Enterprise
Maximum number of PCI Express lanes: 20
PCI Express slots version: 5.0
PCI Express configurations: 2x8+1x4, 1x16+1x4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1

Processor special features

Intel® Turbo Boost Technology: 2.0
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel Trusted Execution Technology
Intel® Turbo Boost Technology 2.0 frequency: 4.5 GHz
Feature: Intel® Total Memory Encryption
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel® Boot Guard
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Virtualization Technology with Redirect Protection (VT-rp)
Microprocessor PCIe Revision: Gen 5
Feature: Intel® Total Memory Encryption - Multi Key

Operational conditions

Tjunction: 100 °C

Logistics data

Harmonized System (HS) code: 8542310001

Technical details

Launch date: Q4'23
Status: Launched
Servicing status: Baseline Servicing

Other features

Maximum internal memory: 128 GB
